Jumo - 603026/0202-1-062-30-0-00-33-00-20-200-15-6/000
Manufacturer | Jumo |
---|---|
Part Number | 603026/0202-1-062-30-0-00-33-00-20-200-15-6/000 |
Inner Code | 1135569 |
Description | Thermostat |
Custom Code | 90321081 |
Technical specification | Part no.: 00422671 According to data sheet 603026 Basic type modular double thermostat, ATH series ATH.-22 type extension Temperature monitor/temperature monitor (TW/TW) Rigid shaft design Control range 50.. 200°C Control range 2 50.. 200°C Switching difference 3% Switching difference 2 3% Process connection protective sleeve with weld collar and Conical spacer Werkst. Procedural. CrNi (stainless steel) Installation length 200 mm Immersion tube diameter 15 mm Sensor diameter 6 mm Sensor material Cu (copper) Switching voltage 230V Switching current 10A cos = 1 Voltage type AC JUMO type plate JUMO DIN approval mark yes From 01.01.2016, the white will be omitted plastic cover over the micro switch. Compliance with standards DIN EN 14597 2015-02 DIN EN 60730-2-9 2011-07 DIN EN 6730-1 2012-1 are fully available. |
Weight | 1 |
Please contact us to request a price quote for Jumo - 603026/0202-1-062-30-0-00-33-00-20-200-15-6/000, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy 603026/0202-1-062-30-0-00-33-00-20-200-15-6/000 by Jumo in United Kingdom?
You can purchase 603026/0202-1-062-30-0-00-33-00-20-200-15-6/000 by Jumo from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the 603026/0202-1-062-30-0-00-33-00-20-200-15-6/000?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Jumo in United Kingdom?
While we are not the official distributor or seller of Jumo in United Kingdom, we source our products from reliable channels and offer you original Jumo equipment at competitive prices.
How can I access 603026/0202-1-062-30-0-00-33-00-20-200-15-6/000 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 603026/0202-1-062-30-0-00-33-00-20-200-15-6/000 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 603026/0202-1-062-30-0-00-33-00-20-200-15-6/000?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
