Kaydon - K20013BROM
Manufacturer | Kaydon |
---|---|
Part Number | K20013BROM |
Inner Code | 3998972 |
Description | bearing |
Technical specification | Bearing Type Ball For Load Direction Angular Construction Single Row Contact Angle 30° Seal Type Open Cross Section 13 mm For Shaft Diameter 200 mm Bore Dia (d) 200 mm Bore Dia Tolerance -0.03mm to 0 For Housing ID 226 mm Outer Dia (D) 226 mm Outer Dia Tolerance -0.03mm to 0 Width (B) 13 mm Width Tolerance +.000 –.254mm Land dia.L1 209.7 Land dia.L2 216.3 C'Bore dia.L3 219.4 Ring Material 52100 Chrome steel Ball Material 52100 Chrome steel Cage Material Brass Dynamic radial (N) 14475 Static (N) Thrust 35137 Radial 36775 Thrust 106177 Lubrication Lubricated Shaft Mount Type Press Fit Temperature Range -30° to 110 ℃ ABEC Rating ABEC-1 Radial Clearance 0.0000 – 0.0005" RoHS Compliant |
Weight | 0.62 |
Please contact us to request a price quote for Kaydon - K20013BROM, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy K20013BROM by Kaydon in United Kingdom?
You can purchase K20013BROM by Kaydon from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the K20013BROM?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Kaydon in United Kingdom?
While we are not the official distributor or seller of Kaydon in United Kingdom, we source our products from reliable channels and offer you original Kaydon equipment at competitive prices.
How can I access K20013BROM catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for K20013BROM on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for K20013BROM?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
