Klinger Born - 8503.4040
| Manufacturer | Klinger Born |
|---|---|
| Part Number | 8503.4040 |
| Inner Code | 3899265 |
| Description | Star Delta Timer |
| Technical specification | Nominal frequency 50-60Hz Voltage range 85-110% Rated power 2VA Ambient temperature -10 ° C ... + 55 ° C Control input K1 Same potential as input L3 Star-delta time domain 0.15 sec ... 30 sec Switchover time star-delta Approx. 60ms Way of working Controller controlled with watch dog B10 (B10d) 400,000 (800,000) Max. Cross section 2.5mm² Attachment On DIN standard rails (EN60715) Dimensions of housing 45.5 x 74 x 85mm (WxHxD) Technical information Wiring diagram 230V DIN rail housing 10-pin Relay outputs nominal voltage 250V AC Continuous current 5A Inrush current 5A Rated switching capacity 1250VA Contact material AgSnO Mechanical life 50x10 6 switching cycles Electrical life at 5A / 250V AC 100x10 3 switching cycles Max. Switching frequency at nominal load 360 switching cycles / h Response time / fall time 10 / 10ms Test voltage contact coil 4000V ACeff Test voltage open contact 750V ACeff Installation position Any Vibration resistance (30 ... 500Hz) G> 4 Shock resistance 11ms G> 10 |
| Weight | 0.15 |
Please contact us to request a price quote for Klinger Born - 8503.4040, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy 8503.4040 by Klinger Born in United Kingdom?
You can purchase 8503.4040 by Klinger Born from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the 8503.4040?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Klinger Born in United Kingdom?
While we are not the official distributor or seller of Klinger Born in United Kingdom, we source our products from reliable channels and offer you original Klinger Born equipment at competitive prices.
How can I access 8503.4040 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 8503.4040 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 8503.4040?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
