Klinger Born - P/N: 106548,Type: ESH-ARO-20A-1205
| Manufacturer | Klinger Born |
|---|---|
| Part Number | P/N: 106548,Type: ESH-ARO-20A-1205 |
| Inner Code | 3899266 |
| Description | SCHALTSCHARNIER |
| Technical specification | Tension Depending on the version 110V, 230V, 400V (+10 ...- 15%) frequency 50 / 60Hz, limited generator operation Braking current Adjustable, regulated, depending on the version 1 ... 30A Engine power Depending on the version 0.18 ... 11kW Performance level PL = b according to DIN EN ISO 13849-1 PFH 4.23x10 -6 h -1 MTTFd 259 years Test no. IFA1203002 Standstill detection Measurement via the third motor connection Error detection standstill 3x braking time longer than 10s ... 13.9s 1x braking time longer than 14s Special designs with fixed braking times Special designs up to 20s Operating display Two LEDs Braking time Automatic adjustment with standstill detection 0.8 ... 10s Delay before restart Approx. 300ms Max. Switching frequency 10% ED at 10 seconds braking time (60 / h) Power dissipation Pv = 400mW (at rest) Pv <= 17W (during braking, depending on the braking current and internal resistance of the motor) Power semiconductor monitoring Overtemperature shutdown (optional) Back-up fuse - load side ASB20: 16A gL ASB20 / 30: 25A gL Back-up fuse - tax side F10A Connections - load Wago spring-type terminals Stripping length 8-9mm cross-section 0.08 - 4.0mm² solid 28-12 AWG 0.25 - 2.5mm² finely stranded with AEH Connections - control circuit Wago spring-type terminals Stripping length 5-6mm cross-section 0.08-2.5mm² solid 28-12 AWG 0.25 - 1.5mm² finely stranded with AEH Housing material PA6.6-GF10-V0 Ambient temperature -10 ° C ... + 45 ° C Storage temperature -25 ° C ... + 75 ° C |
| Weight | 0.796 |
