Kobold - PIT-S206R026H-0302-L-K / UMF2-D14G0BK3
| Manufacturer | Kobold |
|---|---|
| Part Number | PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 |
| Inner Code | 554530 |
| Description | magnetic inductive flowmeter |
| Technical specification | Electro-Magnetic-Flowmeter Model-Code Sensor : PIT-S206R026H-0302-L-K Model-Code Transmitter : UMF2-D14G0BK3 Function Measuring principle : pulsed DC field Operating conditions Flow range [m3/h] : inner diameter needed Fluid : fluid Density [kg/m3] : 1000 Operating temp. [°C] : max. 100 Operating press. [bar g] : max. 16 Flow direction : - please state Sensor informations Wetted parts : SS 1.4571/1.4404/PTFE Process connection : 2" CLASS 150 RF ASME B16.5 Nominal pressure : 16 bar Sensor length "T" : 263 mm (DN700-DN1200) Electrodes : Hastelloy C-4 Earthing electrode : without Ingress protection : IP65 Connection to sensor : separate - terminal box via M20x1,5 Approval : without Fluid temperature limit : 100 °C Staight inlet run : 10 x DN Straight outlet run : 5 x DN Transmitter informations (UMF2) Mounting : separate (-40°C to 100°C Med. temp.) Ingress protection : IP67 Conduit port opening : M20x1,5 Approval : without Explosion proof : without Display : LCD Power supply : 24V DC (+20/-10%) Current output : 4-20 mA with HART®-Protocol Pulse output : passive 24V DC Status output : passive 24V DC forward-/backward flow detection MIN/MAX flow, alarm Ambient temperature : -20 bis 60°C Performance characteristics Accuracy : +/- 1,5% of actual flow +/- 0,5% of full scale Min. conductivity min : 20 μS/cm (100 μS/cm with empty pipe detection) Accessories : - with special coils for low velocities of 0,5 -5 m/s - 15 m cable IP67 incl. junction-box on transmitter - including test-report 2.2 |
| Weight | 1 |
Please contact us to request a price quote for Kobold - PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 by Kobold in United Kingdom?
You can purchase PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 by Kobold from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 ?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Kobold in United Kingdom?
While we are not the official distributor or seller of Kobold in United Kingdom, we source our products from reliable channels and offer you original Kobold equipment at competitive prices.
How can I access PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 ?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
