Ksr Kuebler - BLR-CMZZ44ZP221500ZZ
| Manufacturer | Ksr Kuebler |
|---|---|
| Part Number | BLR-CMZZ44ZP221500ZZ |
| Inner Code | 4689645 |
| Description | level sensor |
| Custom Code | 90261089 |
| Technical specification | CERT31-EG87-BH-CH- - - - - - - BNA-EN25/16/B1-MG-M1.500-V60x2-MRA-ZVSS185/PN25/R48H Bypass level indicator type BNA-SA1 Pressure: 10 bar; temp.: -10°C... 200°C; density, medium: 864 kg/m³ Interpretation: DGRL 2014/68/EU (AD2000) Classification according to DGRL 2014/68/EU: Category I, module A, Fluid group 1 Test pressure: 17 bar Chamber dimensions: 60.3 x 2 mm stainless steel 1.4571 (316Ti) Process connection: DIN EN 1092-1 DN 25 PN 16 form B1 flange Center distance: 1500 mm Measuring range: 1500 mm Upper chamber closure: tube base Lower chamber closure: D130 flange Drain: screw plug G 1/2" Floater: ZVSS185/PN25/R48H Display: BMD-SA, aluminum profile with plastic wheels Damping element: damping spring at the bottom with cover Seal (s): Sigraflex Universal Pro Screws: stainless steel A4-70 (M) Overhang at the top (T): 100 mm Protrusion at the bottom (U): 200 mm Distance from lower process connection to outlet end: 260 mm (max.) Side distance (X): 100 mm (maximum) Type plate: laser-marked aluminum Weight: 17.0 kg MG-APUVK10/MT/TS-L1,650/M1,500/14 Reed bypass mount sensor type BLR-SB Base: 3mm Microtherm Material: stainless steel 1.4571 (316Ti) Housing: polyester IP65 cable fitting M20x1.5 mm LCD display: No Head transmitter: TS - 2-wire, standard, analog Output signal: 4-20 mA Case arrangement: angled at the bottom 100% Brand (L1): 0 mm 0% brand: 0 mm Measuring range: 1500 mm Tube length: 1650 mm Contact grid: 10 mm Case height: 100 mm When using Microtherm, the BLR must not also be insulated will Inspection certificate 3.1 in accordance with EN 10204 Type of certificate: Acceptance test certificate DIN EN 10204 3.1 Testimony language: English and German Certificate/Testimonial for: Bypass Standard Material certificate: Pressure-bearing metallic in contact with the media Components with pre-supplier certificate (melt analysis) Pressure and strength test: Hydrostatic internal pressure test |
| Weight | 17 |
Please contact us to request a price quote for Ksr Kuebler - BLR-CMZZ44ZP221500ZZ, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy BLR-CMZZ44ZP221500ZZ by Ksr Kuebler in United Kingdom?
You can purchase BLR-CMZZ44ZP221500ZZ by Ksr Kuebler from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the BLR-CMZZ44ZP221500ZZ?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Ksr Kuebler in United Kingdom?
While we are not the official distributor or seller of Ksr Kuebler in United Kingdom, we source our products from reliable channels and offer you original Ksr Kuebler equipment at competitive prices.
How can I access BLR-CMZZ44ZP221500ZZ catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for BLR-CMZZ44ZP221500ZZ on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for BLR-CMZZ44ZP221500ZZ?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
