Ksr Kuebler - BNA-EN15/16/B1-M500-V42x2-MRA-2/M-ZTS 35/185

Manufacturer Ksr Kuebler
Part Number BNA-EN15/16/B1-M500-V42x2-MRA-2/M-ZTS 35/185
Inner Code 4493529
Custom Code 90261089
Technical specification Bypass level indicator type BNA-CA1 pressure: 1 bar; temp.: -10°C... 50 °C; density, medium: 850 kg/m³ Design: PED 2014/68/EU (AD2000) Classification according to PED 2014/68/EU: category I, module A, Fluid group 1 Test pressure: 6 bar Chamber dimensions: 42.4 x 2 mm stainless steel 1.4571 (316Ti) Process connection: flange DIN EN 1092-1 DN 15 PN 16 form B1 Center distance: 500 mm Measuring range: 500 mm Float: ZTS35/185 Float material: titanium 3.7035 Chamber closure at the top: tube plate Lower chamber closure: KSR vessel flange Drain: screw plug G 1/2" Damping element: damping element at the bottom Gasket (s): flat gasket, graphite laminate Screws: stainless steel A4-70 (M) protrusion top (T): 100 mm protrusion bottom (U): 200 mm Lateral distance (X): 100 mm (max) Type plate: aluminum laser marked Weight: 8.8 kgs MRA-M500 Indicator for bypass type BMD-SA Measuring range: 500 mm Housing material: anodized aluminum Display element: wheels red/white Ocular: Makrolon PC BGU-1 PVC Magnetic switch for bypass BGU-S Basic type: BGU-S, reed, aluminum housing, cable outlet Max. AC 230 V; 40 VA; 1 A/DC 230 V; 20 W; 0.5 A Number of switches: 2 Electrical connection: cable PVC 1 m Process temperature -40°C to 55°C Protection class: IP66
Weight 8.8

Please contact us to request a price quote for Ksr Kuebler - BNA-EN15/16/B1-M500-V42x2-MRA-2/M-ZTS 35/185, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy BNA-EN15/16/B1-M500-V42x2-MRA-2/M-ZTS 35/185 by Ksr Kuebler in United Kingdom?

You can purchase BNA-EN15/16/B1-M500-V42x2-MRA-2/M-ZTS 35/185 by Ksr Kuebler from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.

What is the price of the BNA-EN15/16/B1-M500-V42x2-MRA-2/M-ZTS 35/185?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Ksr Kuebler in United Kingdom?

While we are not the official distributor or seller of Ksr Kuebler in United Kingdom, we source our products from reliable channels and offer you original Ksr Kuebler equipment at competitive prices.

How can I access BNA-EN15/16/B1-M500-V42x2-MRA-2/M-ZTS 35/185 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for BNA-EN15/16/B1-M500-V42x2-MRA-2/M-ZTS 35/185 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for BNA-EN15/16/B1-M500-V42x2-MRA-2/M-ZTS 35/185?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
