Ksr Kuebler - BNA-2"/150/RF-M1,500-L60x2-MRA-3/M-ZTS165/PN16/A110-Ex
| Manufacturer | Ksr Kuebler |
|---|---|
| Part Number | BNA-2"/150/RF-M1,500-L60x2-MRA-3/M-ZTS165/PN16/A110-Ex |
| Inner Code | 4961927 |
| Description | Magnetic level gauge |
| Custom Code | 90261089 |
| Technical specification | BNA-2"/150/RF M1,500-L60x2-MRA-3/M-ZTS165/PN16/A110-ex Bypass level indicator type BNA-S00C Approval: ATEX Ex h; IBEXU20ATEX1066 X II 1/2G Ex h IIB T6... T1 Ga/Gb, II/2D Exh IIIC T68°C... T360°C -/Db pressure: 5.0 bar; temperature: -10°C... 30 °C; density, medium: 1000 kg/m³ Interpretation: DGRL 2014/68/EU (AD2000) Test pressure: 8 bar Chamber dimensions: 60.3 x 2 mm stainless steel 1.4401/1.4404 (316/316L) Process connection: ASME B16.5 2" Class 150 form RF flange Center distance: 1500 mm Measurement range: 1500 mm Chamber closure at the top: tube base Lower chamber closure: Flange D130 Ventilation: G 1/2" screw plug Drain: needle valve internal thread G 1/2" Swimmer: ZTS165/PN16/A110 Display: BMD-SA, aluminum profile with plastic rollers Damping element: damping spring bottom/top with cover Seal (s): Sigraflex Universal Pro Screws: stainless steel A4-70 (M) Overhang above (T): 100 mm Bottom overhang (U): 200 mm Distance from bottom process connection to outlet end: 370 mm (max.) Side distance (X): 170 mm (maximum) Type plate: laser marked aluminum Weight: 18.2 kg BGU-E-1 PVC BGU-SI bypass magnetic switch Basic type: BGU-S, reed, aluminum housing, cable outlet Ui = 36V; Ii = 100mA; Pi = 0.84W Number of switches: 3 Approval: IBExU 18 ATEX 1108X II 2G Exib IIC T6... T1 Gb, II 2D Exib IIIC T80°C... 180°C Db Electrical connection: 1 m PVC cable Process temperature -40°C to 55°C allowable ambient temperature: -40°C... +80°C max. operating temperature TB at installation location: 80°C (T6-T1) max. surface temperature for dust: TB + 5K Protection class: IP66 TAG-1 (VA shield) 10LDP10 CL501 Customs tariff number: 90261089 |
| Weight | 18.2 |
