Ksr Kuebler - BNA-20/40/C-MG-M1100-V60x2-MRF-ZVSS 245-Ex

Manufacturer Ksr Kuebler
Part Number BNA-20/40/C-MG-M1100-V60x2-MRF-ZVSS 245-Ex
Inner Code 5132487
Custom Code 90261089
Technical specification

BNA-20/40/C-Mg-M1,100-V60x2-MRF-zvss 245-Ex
Bypass level indicator type BNA-S00C
Approval: ATEX Ex h; IBEXU20ATEX1066 X II 1/2G Ex h IIC T6... T1
Ga/Gb, II/2D Exh IIIC
T68°C... T360°C -/Db
pressure: 11.0 bar; temperature: -10°C... 250°C; density, medium: 883 kg/m³
Interpretation: DGRL 2014/68/EU (AD2000)

Test pressure: 20 bar
Chamber dimensions: 60.3 x 2 mm stainless steel 1.4571 (316Ti)
Process connection: Flange DIN DN 20 PN 40 Form C
Center distance: 1100 mm
Measurement range: 1100 mm
Chamber closure at the top: tube base
Lower chamber closure: Flange D130
Ohne
Drain: needle valve internal thread G 1/2" (closed with screw)
Damping element: damping spring bottom/top with cover
Seal (s): Sigraflex Universal Pro
Screws: stainless steel A4-70 (M)
Overhang above (T): 100 mm
Bottom overhang (U): 250 mm
Distance from bottom process connection to outlet end: 420 mm (max.)
Side distance (X): 100 mm (maximum)
Nameplate: laser marked aluminum
ZVSS 245
BFT-S bypass float
Material: stainless steel
Test pressure: 14.3 bar (float only)
Density, medium: 883 kg/m³
MRF-M1,100
BMD-FA bypass indicator
Measurement range: 1100 mm
Case material: anodized aluminum
Indicator: red/white stainless steel flaps
Lens: glass
MG-AUVK10/MT-L1250/M1100/14-Ex
Reed bypass sensor type BLR-SAI
Approval: ATEX - Ex i; KEMA 01ATEX1052 X II 2G Ex ia IIC T6... T1
Gb - II 2D Ex ib IIIC
T80°C... T230°C Db
Base: 3 mm Microtherm
Material: stainless steel 1.4571 (316Ti)
Housing: aluminum IP66/IP68 cable screw M20x1.5 mm
LCD display: Without

Case layout: Downward angled
100% brand (L1): 0 mm
0% brand: 0 mm
Measurement range: 1100 mm
Tube length: 1250 mm
contact grid: 10 mm
Case height: 60 mm
***
Additional order information: Attention! Max. temperature at
Sensor tube +100°C. Sensor must not
be isolated.
When using Microtherm, the BLR must not be insulated
will
Permissible temperatures for the bypass mount sensor (BLR):
Allowable
The surface temperature of the pipe and the ambient temperature of
For housing, see note in
MuB
Weight 14.5
