Ksr Kuebler - BNA-EN20/100/B2-M600-V60x2.77-MRF-ZTS350/PN100/A110
| Manufacturer | Ksr Kuebler |
|---|---|
| Part Number | BNA-EN20/100/B2-M600-V60x2.77-MRF-ZTS350/PN100/A110 |
| Inner Code | 5039006 |
| Custom Code | 90261089 |
| Technical specification | Bypass level indicator type BNA-SA2 pressure: 70.0 bar; temperature: -10°C... 300 °C; density, medium: 712 kg/m³ Interpretation: DGRL 2014/68/EU (AD2000) Classification according to DGRL 2014/68/EU: Category II, Module A2, Fluid group 1 Test pressure: 136 bar Chamber dimensions: 60.3 x 2.77 mm stainless steel 1.4571 (316Ti) Process connection: flange DIN EN 1092-1 DN 20 PN 100 form B2 Center distance: 600 mm Measurement range: 600 mm Chamber closure at the top: tube base Lower chamber closure: flange DIN EN 1092-1 DN 50 PN 100 Form B2 Drain: G 1/2" plug Display: BMD-FA, aluminum profile with stainless steel flaps Damping element: damping spring at the bottom with cover Seal (s): flat gasket base material + graphite Screws: stainless steel A4-70 (M) Overhang above (T): 100 mm Bottom overhang (U): 330 mm Distance from bottom process connection to outlet end: 390 mm (max.) Side distance (X): 170 mm (maximum) Type plate: laser marked aluminum ZTS350/PN100/A110 BFT-H bypass float Material: titanium Test pressure: 91.0 bar (float only) Density, medium: 712 kg/m³ Acceptance test certificate 3.1 in accordance with EN 10204 Certificate type: Acceptance test certificate DIN EN 10204 3.1 Certificate language: English and German Certificate/Testimonial for: Bypass Standard Material Certificate: Pressure-bearing metallic in contact with media Components with pre-supplier certificate (melt analysis) Pressure and strength test: hydrostatic internal pressure test |
| Weight | 27 |
Please contact us to request a price quote for Ksr Kuebler - BNA-EN20/100/B2-M600-V60x2.77-MRF-ZTS350/PN100/A110, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
