Ksr Kuebler - BNA-P00
| Manufacturer | Ksr Kuebler |
|---|---|
| Part Number | BNA-P00 |
| Inner Code | 4953304 |
| Technical specification | 83192090 BNA-1"/150/RF-M1,300-PP63x3-MRA/SKC-ZPPS 200 Magnetic Level Gauge Type BNA-P00 Pressure: 0.5 bar ; Temp.: -10°C...40°C; Fluid density: 1174 kg/m³ Test pressure: 9.0 bar Chamber dimensions: OD 63 x 3 mm Polypropylene (PP) Float: ZPPS 200 Process connection: Flange ASME B16.5 1" 150# Form RF (Loose flange) Distance C-to-C: 1300 mm Measuring range: 1300 mm Chamber end top: Thread DN 50 Chamber end bottom: Thread DN50 Vent connection: Vent plug 1/2"NPT Drain connection: Drain plug 1/2"NPT Gasket(s): O-Ring, EPDM Top stand-off (T): 170 mm Bottom stand-off (U): 195 mm Side distance (X): 170 mm Nameplate: Adhesive label Weight: 6.9 kg MRA/SKC-M1,300 Level Indicator for Magnetic Level Gauge Type BMD-SA Measuring range: 1300 mm Housing material: Aluminium anodized Indicating elements: Rollers Red & white Graduated scale: Adhesive foil on aluminium Graduation unit: cm Indicator window: Makrolon PC |
| Weight | 7 |
Please contact us to request a price quote for Ksr Kuebler - BNA-P00, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
