Ksr Kuebler - Typ UTN-S00C(UTN-2"/150/RF-MG-L950/M600-V60x2-MRAV-ZTS50/300/PN16/UTN/R48-Ex)

Manufacturer Ksr Kuebler
Part Number Typ UTN-S00C(UTN-2"/150/RF-MG-L950/M600-V60x2-MRAV-ZTS50/300/PN16/UTN/R48-Ex)
Inner Code 5145037
Technical specification

UTN-2"/150/RF-MG-L950/M600-V60x2-MRAV-ZTS50/300/PN16/UTN/R48-Ex
Overtank indicator type UTN-S00C
Approval: ATEX Ex h; IBEXU20ATEX1066 X II 1/2G Ex h IIB T6... T1
Ga/Gb, II/2D Exh IIIC
T68°C... T360°C -/Db
pressure: 0.5 bar; temperature: -20°C... 100°C; density, medium: 1000 kg/m³
Interpretation: DGRL 2014/68/EU (AD2000)
Classification according to DGRL 2014/68/EU: None
Test pressure: 3 bar
Chamber dimensions: 60.3 x 2 mm stainless steel 1.4571 (316Ti)
Process connection: ASME B16.5 2" Class 150 form RF flange
Installation length (L): 950 mm
Measurement range: 600 mm
Overhang above (T): 150 mm
Bottom overhang (U): 120mm
Length of the guide sleeve (X): 50 mm
Type plate: laser coated aluminum
ZTS50/300/PN16/UTN/R48
Bypass float
Float material: titanium
Test pressure: 1 bar (float only)
Density, medium: 1000 kg/m³
UTN magnetic system: R48
Push rod: titanium, Ø 10 x 1 mm
Push rod length: 739 mm
UTN float weight: 357 g
surfaced height (F): 115 mm
MRAV-M450
BMD-SR bypass indicator
Measurement range: 450 mm
Case material: stainless steel, 316
Indicator: red/white rollers
Lens: Makrolon PC
MG-AV4VK18/T38-L750/M600/14-Ex
Reed Bypass Mount Sensor Type BLR-SBI
Approval: ATEX - Ex i; KEMA 01ATEX1052 X II 2G Ex ia IIC T6... T1

Gb - II 2D Ex ib IIIC
T80°C... T230°C Db
Material: stainless steel 1.4571 (316Ti)
Housing: stainless steel IP66/IP68 cable fitting M20x1.5 mm
LCD display: Without
Head transmitter: T38 - 2-wire Ex i Hart 7 programmable
Output signal: 4-20 mA - HART
Case layout: Upward angled
100% brand (L1): 0 mm
0% brand: 0 mm
Measurement range: 600 mm
Tube length: 750 mm
contact grid: 18 mm
Permissible temperatures for the bypass mount sensor (BLR):
Allowable
The surface temperature of the pipe and the ambient temperature of
For housing, see note in MuB
Acceptance test certificate 3.1 in accordance with EN 10204
Certificate type: Acceptance test certificate DIN EN 10204 3.1
Certificate language: English and German
Certificate/Testimonial for: Overtank indicator
Material Certificate: Pressure-bearing metallic in contact with media
Components with pre-supplier certificate
(melt analysis)
Pressure and strength test: hydrostatic internal pressure test
Weight 1
