Ksr Kuebler - BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250
| Manufacturer | Ksr Kuebler |
|---|---|
| Part Number | BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250 |
| Inner Code | 4455445 |
| Description | Bypass level gauges |
| Custom Code | 90261089 |
| Technical specification | BNA-CMB02000215-0100400D0880DZZS BNA-BMDGAECEARZZZZZZZHZZZGAZZ12KVB25031ZZZZ BLR-CMZZ4WZA210400Z# BGU-C5ZZS2ZZZZZZ pressure: 20 bar temp.: -10°C... 215 °Cdensity, medium: 880 kg/m³ Design: PED 2014/68/EU (AD2000) Classification according to PED 2014/68/EU: category I, module A, fluid group 1 Test pressure: 36 bar Chamber dimensions: 60.3 x 2 mm stainless steel 1.4571 (316Ti) Process connection: flange DIN EN 1092-1 DN 20 PN 40 form B1 Centre distance: 400 mm Measuring range: 400 mm Chamber termination top: tube base Bottom chamber end: flange D130 Drain: plug screw G 1/2" Floats: ZVSS250 Display: BMD-FA, aluminum profile with stainless steel flaps Damping element: damping spring at the bottom with cover Seal (s): Sigraflex Universal Pro Screws: stainless steel A4-70 (M) overhang top (T): 100 mm projection bottom (U): 225 mm Side spacing (X): 100 mm (max) BGU-VHT Magnetic switch for bypass BGU-VHT Basic type: BGU-VHT, reed, high temperature, stainless steel housing, cable gland Max. AC 230 V, 40 VA, 1 A/DC 230 V, 20 W, 0.5 A Number of switches: 3 Electrical connection: cable gland M20x1.5 mm Process temperature -60°C to 380°C Add Microtherm pad to switch Protection class: IP66/68 Magnetic switch on the right of the roller display MG-AVK15/MT-L550/M400/14 Transmitter bypass mounting Reed type BLR-SA Pad: 3 mm microtherm Material: stainless steel 1.4571 (316Ti) Housing: aluminium IP66/68 cable gland M20 x 1.5 mm LCD display: None Output signal: 3-wire potentiometer Housing arrangement: angled at the top 100% brand (L1): 0 mm 0% mark: 0 mm Measuring range: 400 mm Tube length: 550 mm Contact grid: 15 mm *** Additional order information: - Total resistance approx. 3-10kOhm The BLR must not be insulated when using Microtherm |
| Weight | 10.2 |
Please contact us to request a price quote for Ksr Kuebler - BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250 by Ksr Kuebler in United Kingdom?
You can purchase BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250 by Ksr Kuebler from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Ksr Kuebler in United Kingdom?
While we are not the official distributor or seller of Ksr Kuebler in United Kingdom, we source our products from reliable channels and offer you original Ksr Kuebler equipment at competitive prices.
How can I access BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
