Leadshine - CS-M23480

Manufacturer Leadshine
Part Number CS-M23480
Inner Code 5147338
Technical specification

Article M016837

Specification
Hybrid stepper motor with encoder motor type
34Flange NEMA nema
86.0Flange size x mm
86.0Flange size y mm
14.0Shaft Dia mm
40.0Shaft length mm
126.0Engine length mm
2No. of stacks
2No. of phases
1.8Step angle degree
6.0Rated current per phase A
0.63Resistance per phase ohms

Resistance per phase tolerance percent
4.0Inductance per phase mH
20Inductance per phase tolerance percent
8.0Holding torque Nm
2500.0Rotor inertia gcm2
100.0Insulation resistance at 500VDC MOhm
3.5Weight kg kg
270.0Lead wires length mm
14.0Rear shaft diameter mm
40.0Rear shaft length mm
4000 ENC counts per turn

Weight 3.5
