Leadshine - M102155 - 57CM22C

Manufacturer Leadshine
Part Number M102155 - 57CM22C
Inner Code 5122088
Technical specification

Specification
Hybrid stepper motorMotor type
23Flange NEMA nema
56.4Flange size x mm
56.4Flange size y mm
8.0Shaft Dia mm
21.0Shaft length mm
74.0 Engine length mm
+/-1Length tolerance mm
2No. of phases
1.8Step angle degree
5.0Rated current per phase A
0.38Resistance per phase ohms
+/-10Resistance per phase tolerance percent
1.6Inductance per phase mH
+/-20 inductance per phase tolerance percent
2.2Holding torque Nm
480.0Rotor inertia gcm2
IP40 protection class

Specification
100.0Insulation resistance at 500VDC MOhm
80.0Heat rise °C
1.1Weight kg kg
400.0Lead wires length mm

Weight 1.1
