Leuze - p/n: 50117201, Type: ISS 208MM/4NO-2E0-S8.3
| Manufacturer | Leuze |
|---|---|
| Part Number | p/n: 50117201, Type: ISS 208MM/4NO-2E0-S8.3 |
| Inner Code | 1496454 |
| Description | Induktiver Sensor |
| Custom Code | 85365019 |
| Technical specification | 208 series type. Range limit Sn 2 mm Operating range Sa 0... 1.6 mm 208 series type. Range limit Sn 2 mm Operating range Sa 0... 1.6 mm Supply voltage UB 10... 30 V, DC Residual ripple 0... 20%, from UB Idle current 0... 10 mA Temperature drift, max. (in% of Sr) 10%, over the entire operating temperature range Repeatability, max. (in% of Sr) 5%, at UB = 20... 30 V DC, ambient temperature Ta = 23°C ± 5°C Switch hysteresis 10% Number of digital switching outputs 1 piece (s) Number of digital switching outputs 1 piece (s) Transistor switching element, PNP Closer switching principle (NO) Switching frequency 5,000 Hz Standby delay 32 ms Switching frequency 5,000 Hz Standby delay 32 ms Switching frequency 5,000 Hz Standby delay 32 ms Cylindrical design Thread size M8 x 1 mm Dimensions (diameter x length) 8 mm x 32 mm Installation type flush Housing material stainless steel V2A stainless steel case Active surface material Plastic, polyamide (PA 12) Net weight 11 g Housing color red, RAL 3000 silver Type of fastening Fastening thread via optional mounting part Standard measurement plate 8 x 8 mm², Fe360 Cylindrical design Thread size M8 x 1 mm Dimensions (diameter x length) 8 mm x 32 mm Installation type flush Housing material stainless steel V2A stainless steel case Active surface material Plastic, polyamide (PA 12) Net weight 11 g Housing color red, RAL 3000 silver Type of fastening Fastening thread via optional mounting part Standard measurement plate 8 x 8 mm², Fe360 Cylindrical design Thread size M8 x 1 mm Dimensions (diameter x length) 8 mm x 32 mm Installation type flush Housing material stainless steel V2A stainless steel case Active surface material Plastic, polyamide (PA 12) Net weight 11 g Housing color red, RAL 3000 silver Type of fastening Fastening thread via optional mounting part Standard measurement plate 8 x 8 mm², Fe360 Protection class IP 67 Safety class III c UL US approvals EMC test methods in accordance with the IEC 61000-4-2 standard IEC 61000-4-3 IEC 61000-4-4 Valid set of standards IEC 60947-5-2 Protection class IP 67 Safety class III c UL US approvals EMC test methods in accordance with the IEC 61000-4-2 standard IEC 61000-4-3 IEC 61000-4-4 Valid set of standards IEC 60947-5-2 |
| Weight | 0.011 |
Please contact us to request a price quote for Leuze - p/n: 50117201, Type: ISS 208MM/4NO-2E0-S8.3, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy p/n: 50117201, Type: ISS 208MM/4NO-2E0-S8.3 by Leuze in United Kingdom?
You can purchase p/n: 50117201, Type: ISS 208MM/4NO-2E0-S8.3 by Leuze from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the p/n: 50117201, Type: ISS 208MM/4NO-2E0-S8.3?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Leuze in United Kingdom?
While we are not the official distributor or seller of Leuze in United Kingdom, we source our products from reliable channels and offer you original Leuze equipment at competitive prices.
How can I access p/n: 50117201, Type: ISS 208MM/4NO-2E0-S8.3 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for p/n: 50117201, Type: ISS 208MM/4NO-2E0-S8.3 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for p/n: 50117201, Type: ISS 208MM/4NO-2E0-S8.3?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
