Leybold - D65BCS (Part No. 113 98)
| Manufacturer | Leybold |
|---|---|
| Part Number | D65BCS (Part No. 113 98) |
| Inner Code | 4670415 |
| Description | two stage rotary vane pump |
| Custom Code | 84141025 |
| Technical specification | Oil-sealed vacuum pump with integrated oil pump for Forced lubrication of the bearings even at high suction pressures of 1013 mbar. The pump is free of non-ferrous metals and the inner part of the pump is metallically sealed i.e. no use of elastomer Seals that can be chemically damaged. The TRIVAC BCS The pump has a hydropneumatic suction nozzle valve for vacuum protection and via a gas ballast device with which it It is possible to pump condensable vapors. Engine certification: CSA, UR Pump certification: CE RoHS compliant Technical details: Suction speed according to DIN 28400:65 m³/h (50 Hz)/78 m³/h (60 Hz) Final partial pressure without gas ballast: 10-4 mbar Total final pressure with gas ballast: < 5·10-3 mbar Noise level according to DIN 45 635 with/with gas ballast: 57/59 dB (A) Dimensions (LxWxH): 797 x 235 x 361 mm Oil filling min/max: 2.0/ 3.3 l Including oil filling with LVO 100 Weight: 84.5 kg Engine data: Rated power of the three-phase motor 2,2 kW Rated speed: 1460 min-1 (50 Hz)/1760 min-1 (60 Hz) Efficiency class: IE3 Protection class: IP55 200-240 V; 50 Hz; 9.0 A/200-240 V; 60 Hz; 8.8 A 200 V; 50 Hz; 9 A (IE3 = 86.7%) 208-240 V; 60 Hz; 7.8 A (IE3 = 89.5%) 380-400 V; 50 Hz; 4.5 A/400-480 V; 60 Hz; 4.4 A 380-400 V; 50 Hz; 4.5 A (IE3 = 86.7%) 416-480 V; 60 Hz; 3.9 A (IE3= 89.5%) Suitable for line voltages +/- 10% Suction flange: DN40KF can be used horizontally and vertically Outlet flange: DN40KF can be used horizontally and vertically cooling: air equipment: Manual gas ballast setup (on/off) Inert gas connection for gas ballast M16x1.5 Inert gas connection for the M16x1.5 oil box oil drain and oil filler plug |
| Weight | 84.5 |
Please contact us to request a price quote for Leybold - D65BCS (Part No. 113 98), or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
