Leybold - TRIVAC D16B-DOT 11406
| Manufacturer | Leybold |
|---|---|
| Part Number | TRIVAC D16B-DOT 11406 |
| Inner Code | 547570 |
| Description | Two stage rotary vane pump |
| Custom Code | 84141025 |
| Technical specification | Features: Oil-sealed vacuum pump with integrated oil pump for Forced lubrication of the bearings even at high suction pressures of 1013 mbar. The pump is free of non-ferrous metals and the inner part of the pump is metallically sealed, i.e. no use of elastomeric Seals that can be chemically attacked. The TRIVAC B The pump has a hydropneumatic suction port valve for vacuum protection and via a gas ballast device, with which It is possible to pump condensable vapors. Engine certification: CSA, UR Pump certification: CE RoHS compliant Technical data: Pumping speed in accordance with DIN 28400:16.5 m³/h (50 Hz)/19.8 m³/h (60 Hz) Ultimate total pressure without gas ballast: < 6 · 10-1 mbar Ultimate total pressure with gas ballast: < 9 · 10-1 mbar Sound level according to DIN 45 635 without/with gas ballast: 54/ 56 dB (A) Dimensions (LxWxH): 510 x 186 x 250 mm Oil filling min/max: 0.5/1.0 l Includes oil filling with DOT 4 Weight: 32 kg Motor data: Nominal power of the three-phase motor 750 W Rated speed: 1430 min-1 (50 Hz)/1740 min-1 (60 Hz) Efficiency class: IE2 Protection class: IP55 200-240 V; 50 Hz; 3.6 A/200-240 V; 60 Hz; 3.2 A 200 V; 50 Hz; 3.6 A (IE2)/208-240 V; 60 Hz; 3.4 A (ePACT) 380-400 V; 50 Hz; 1.8 A/380-480 V; 60 Hz; 1.6A 380-400 V; 50 Hz; 1.8 A (IE2)/416-480 V; 60 Hz; 1.7 A (ePACT) Suitable for line voltages +/- 10% Suction flange: DN25KF can be used horizontally and vertically Outlet flange: DN25KF can be used horizontally and vertically Cooling: air equipment: Manual gas ballast device (on/off) Inert gas connection for the M16x1.5 gas ballast Inert gas connection for the M16x1.5 oil box oil drain and oil filler plug Package includes: instruction manual Spare parts list 2 x centering and clamping rings DOT 4 oil filling |
| Weight | 1 |
Please contact us to request a price quote for Leybold - TRIVAC D16B-DOT 11406, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy TRIVAC D16B-DOT 11406 by Leybold in United Kingdom?
You can purchase TRIVAC D16B-DOT 11406 by Leybold from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the TRIVAC D16B-DOT 11406?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Leybold in United Kingdom?
While we are not the official distributor or seller of Leybold in United Kingdom, we source our products from reliable channels and offer you original Leybold equipment at competitive prices.
How can I access TRIVAC D16B-DOT 11406 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for TRIVAC D16B-DOT 11406 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for TRIVAC D16B-DOT 11406?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
