Lowara - ESHE 65-160/11/P46PSNA
| Manufacturer | Lowara |
|---|---|
| Part Number | ESHE 65-160/11/P46PSNA |
| Inner Code | 3372230 |
| Technical specification | Stainless steel AISi 316 centrifugal electric pumps based on EN 733. PUMP COUPLING MOTOR e-SHE Close-coupled by means of an adaptor bracket with an impeller keyed directly to the motor shaft extension CONSTRUCTION FEATURES Single-impeller centrifugal pump featuring axial intake and radial discharge. Liquid end size and suction and delivery port DN based on EN 733 (ex DIN 24255) and UNI 7467. Flanges in compliance with UNI 2236 and DIN 2532. Back pull-out design; (impeller, adapter and motor can be extracted without disconnecting the pump body from the pipes). WORKING POINT: Fluid: Water, pure Flow: 0 m³/h Head: 0 m Temperature: 4 °C Working pressure: 0 bar Delivery port: DN 65 / PN12 Suction port: DN 80 / PN12 Motor: 3~220V/60Hz MOTOR Nominal power: 1,1 kW Speed: 1750 1/min Make: Lowara Degree of protection: IP 55 Frame size: 90 Motor design: IE3 Three phase surface motor SHAFT SEAL Type: Single Seal Material combination Rotating Assembly: V-Ceramic Fixed Assembly: B-Resin impregnated carbon Elastomers: V-FKM (FPM) Springs: G-AISI 316 Other Components: G-AISI 316 PUMP Material combination Pump body: Stainless steel / AISI 316L impeller: Stainless steel / ASTM CF8M (AISI 316 cast) Seal casing: Stainless steel / AISI 316L Wear ring: Stainless steel / AISI 316L Counterwear ring: Stainless steel / AISI 316L Shaft extension: Stainless steel / AISI 316 Rigid shaft coupling: Stainless steel / AISI 316 Impeller locknut and washer: Stainless steel / AISI 316 Tab: Stainless steel / AISI 316L Fill/drain plugs: Stainless steel / AISI 316 |
| Weight | 1 |
Please contact us to request a price quote for Lowara - ESHE 65-160/11/P46PSNA, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy ESHE 65-160/11/P46PSNA by Lowara in United Kingdom?
You can purchase ESHE 65-160/11/P46PSNA by Lowara from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the ESHE 65-160/11/P46PSNA?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Lowara in United Kingdom?
While we are not the official distributor or seller of Lowara in United Kingdom, we source our products from reliable channels and offer you original Lowara equipment at competitive prices.
How can I access ESHE 65-160/11/P46PSNA catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for ESHE 65-160/11/P46PSNA on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for ESHE 65-160/11/P46PSNA?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
