Lowara - P/N: 101880670 Type: LNEE 50-160/30/P25RCS4
| Manufacturer | Lowara |
|---|---|
| Part Number | P/N: 101880670 Type: LNEE 50-160/30/P25RCS4 |
| Inner Code | 3347758 |
| Technical specification | LNEE 50-160/30/P25RCS4 In-line electric pumps with cast iron pump body, AISI 316L stainless steel impeller entirely welded using laser technology up to size 80-160. Cast iron or bronze impeller for larger sizes. CONSTRUCTION FEATURES Pump close-coupled by means of an adapter, with impeller keyed directly to the motor shaft extension. Back pull-out design; (impeller, adapter and motor can be extracted without disconnecting the pump body from the pipes). WORKING POINT: Fluid: Water, pure Flow: 48 m³/h Head: 13 m Temperature: 4 °C Working pressure: 0 kPa Delivery port: DN 50 / PN16 Suction port: DN 50 / PN16 Motor: 3~380V/50Hz MOTOR Nominal power: 3 kW Speed: 2900 1/min Make: Lowara Degree of protection: IP 55 Frame size: 90 Motor design: IE3 Three phase surface motor SHAFT SEAL Type: Mechanical Seal Material combination Rotating Assembly: B-Resin impregnated carbon Fixed Assembly: Q1-Silicon carbide Elastomers: E - EPDM Springs: G-AISI 316 Other Components: G-AISI 316 PUMP Material combination Volute casing: Cast iron Casing cover: Cast iron impeller: Stainless steel / AISI 316L Stub shaft: Stainless steel / AISI 316L Wear ring: Stainless steel / AISI 304 Impeller lock nut and washer: Stainless steel / AISI 316 Impeller key: Stainless steel / AISI 316L Fill and drain plugs: Nickel-plated brass |
| Weight | 46 |
Please contact us to request a price quote for Lowara - P/N: 101880670 Type: LNEE 50-160/30/P25RCS4 , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy P/N: 101880670 Type: LNEE 50-160/30/P25RCS4 by Lowara in United Kingdom?
You can purchase P/N: 101880670 Type: LNEE 50-160/30/P25RCS4 by Lowara from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the P/N: 101880670 Type: LNEE 50-160/30/P25RCS4 ?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Lowara in United Kingdom?
While we are not the official distributor or seller of Lowara in United Kingdom, we source our products from reliable channels and offer you original Lowara equipment at competitive prices.
How can I access P/N: 101880670 Type: LNEE 50-160/30/P25RCS4 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for P/N: 101880670 Type: LNEE 50-160/30/P25RCS4 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for P/N: 101880670 Type: LNEE 50-160/30/P25RCS4 ?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
