Mannesmann-Demag - EKDH 412 H20 KV2 - 4/1 F6

Manufacturer Mannesmann-Demag
Part Number EKDH 412 H20 KV2 - 4/1 F6
Inner Code 5081297
Technical specification

Short-height monorail trolley with electrically powered chassis
Classification according to FEM in group 3m, version according to document
Including electrical control
Electromechanical load control in accordance with EC Machinery Directive
The monorail cat is designed for use in the hall under normal environmental conditions and
Ambient temperatures from -10°C to +40°C.

Hoist technical data:
Load capacity 5000 kg
Hook path 10.00 m
Rope diameter 11.0 mm
Main lift:

Speed 4.0 m/min
Power 3.60 kW
Operating time 40% ED
Fine stroke:
Speed 0.6 m/min
Power 0.53 kW
Operating time 20% ED
engine:
KBH125 B 2/12 main lift motor
Cat chassis technical data:
flange width 300 mm
Impeller type cylindrical
1. Speed 5.0 m/min
Power 0.09 kW
Operating time 40% ED
2.Speed 20.0 m/min
Power 0.34 kW
Operating time 40% ED
ZBF 71 A 8/2 traction motor
Electrical technical data:
Operating voltage 415 V
Control voltage 230 V
Frequency 50 Hz
Current type three-phase
Motor protection class IP 55
Traction motor protection class IP 55
Electrical control is carried out by contactor control
with transformer
with crane contactor
with DST control switch on 5.0 m cable
Further equipment:
Operating limit switch for highest and lowest hook position
PA 12 acid-resistant rope guide
Cable lubricant for lubricating the rope when it is first used
Motor protection with wrapped cold conductors for shutdown at 160°C
230 V trigger
Bare parts preserved
Weight 290
