Maxon - part no:DCX22L GB KL 18V
| Manufacturer | Maxon |
|---|---|
| Part Number | part no:DCX22L GB KL 18V |
| Inner Code | 4802253 |
| Description | DC motor |
| Technical specification | GPX22 A 28:1 gearbox VALUES AT NOMINAL VOLTAGE Nominal voltage 18 V No load speed 11800 rpm No load current 54.6 mA Nominal speed 10800 rpm Nominal torque (max. continuous torque) 32.2 mNm Nominal current (max. continuous current) 2.26 A Stall torque 386 mNm Stall current 26.5 A Max. efficiency 91 % CHARACTERISTICS Terminal resistance 0.68 Ω Terminal inductance 0.0779 mH Torque constant 14.6 mNm/A Speed constant 654 rpm/V Speed / torque gradient 30.5 rpm/mNm Mechanical time constant 3.13 ms Rotor inertia 9.82 gcm² THERMAL DATA Thermal resistance housing-ambient 13.6 K/W Thermal resistance winding-housing 4.57 K/W Thermal time constant winding 23.4 s Thermal time constant motor 646 s Ambient temperature -40...+100 °C Max. winding temperature +125 °C MECHANICAL DATA Bearing type Waelzlager Max. speed 18000 rpm Axial play 0 mm, at radial load < 2.5 N 0.1 mm, at radial load > 2.5 N Radial play 0.02 mm Max. axial load (dynamic) 2.5 N Max. force for press fits (static) 30 N (static, shaft supported) 440 N Max. radial load 16 N, 5 mm from flange OTHER SPECIFICATIONS Number of pole pairs 1 Number of commutator segments 9 Number of autoclave cycles 0 PRODUCT Weight 95 g |
| Weight | 1 |
Please contact us to request a price quote for Maxon - part no:DCX22L GB KL 18V, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy part no:DCX22L GB KL 18V by Maxon in United Kingdom?
You can purchase part no:DCX22L GB KL 18V by Maxon from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the part no:DCX22L GB KL 18V?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Maxon in United Kingdom?
While we are not the official distributor or seller of Maxon in United Kingdom, we source our products from reliable channels and offer you original Maxon equipment at competitive prices.
How can I access part no:DCX22L GB KL 18V catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for part no:DCX22L GB KL 18V on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for part no:DCX22L GB KL 18V?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
