Merkle - DHZ 160.125/70.05.204.300 S.AA11.EG44.DD22.V
| Manufacturer | Merkle |
|---|---|
| Part Number | DHZ 160.125/70.05.204.300 S.AA11.EG44.DD22.V |
| Inner Code | 4995492 |
| Custom Code | 84122180 |
| Technical specification | Article 226368 AHP hydraulic cylinder DHZ 160.125/70.05.204.300 S.AA11.EG44.DD22.V Weight 97 kg Drawing number 13.72981.04 Customs tariff no./ origin 84122180/DE Type DIN cylinder 160bar cylinder type designation DHZ 160 Piston diameter 125 mm Bar diameter 70 mm Design 05 = rectangular rear flange Function type 204 = double-acting with end-position damping on both sides Stroke 300 mm Special S = special cylinder, deviating from the AHP standard Viton sealing type - up to max. 180°C Venting EG44 = venting screw G1/4" on the top and bottom in position 4 Position DD22 damping = damping screw on the head side and on the ground side in position 2 Connection changed AA11 = pipe thread connection on the top and bottom side to position 1 max. operating pressure 160 bar |
| Weight | 97 |
Please contact us to request a price quote for Merkle - DHZ 160.125/70.05.204.300 S.AA11.EG44.DD22.V, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy DHZ 160.125/70.05.204.300 S.AA11.EG44.DD22.V by Merkle in United Kingdom?
You can purchase DHZ 160.125/70.05.204.300 S.AA11.EG44.DD22.V by Merkle from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the DHZ 160.125/70.05.204.300 S.AA11.EG44.DD22.V?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Merkle in United Kingdom?
While we are not the official distributor or seller of Merkle in United Kingdom, we source our products from reliable channels and offer you original Merkle equipment at competitive prices.
How can I access DHZ 160.125/70.05.204.300 S.AA11.EG44.DD22.V catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for DHZ 160.125/70.05.204.300 S.AA11.EG44.DD22.V on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for DHZ 160.125/70.05.204.300 S.AA11.EG44.DD22.V?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
