Merkle - HZH 250.40/25.02.204.450 S.E.G4.M1
| Manufacturer | Merkle |
|---|---|
| Part Number | HZH 250.40/25.02.204.450 S.E.G4.M1 |
| Inner Code | 5111482 |
| Custom Code | 84122180 |
| Technical specification | Article 288940 AHP hydraulic cylinder HZH 250.40/25.02.204.450 S.E.G4.M1 Weight 7.5 kg Drawing number 13.70717.14 Customs tariff no./ origin 84122180/DE Type hydraulic cylinder with dipp® system Cylinder type HZH 250 designation Piston diameter 40 mm Bar diameter 25 mm Design 02 = front flange mounting Function type 204 = double-acting with end-position damping on both sides Hub 450 mm Special S = special cylinder, deviating from the AHP standard Ventilation Ventilation 90° to the left to the connection max. operating pressure 250 bar Piston rod end G4 = with safety thread in accordance with 5.533.04 and DIN 913 weight pin and internal length. Kstg. Wt/length g2 = M16, g3 = 25mm Bar overhang L2 18 mm Please pay attention to buckling resistance! (according to AHP 61006254) |
| Weight | 7.5 |
Please contact us to request a price quote for Merkle - HZH 250.40/25.02.204.450 S.E.G4.M1, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
