Micro-Epsilon (Eltrotec) - CSmi-SF15-C6/3
| Manufacturer | Micro-Epsilon (Eltrotec) |
|---|---|
| Part Number | CSmi-SF15-C6/3 |
| Inner Code | 4819163 |
| Custom Code | 90251900 |
| Technical specification | 4800523.063 Temperature range: -40 to 1030 °C Optical resolution: 15:1 Focus: 0,8 mm @ 10 mm (optional with CF-lense) Spectral range: 8 – 14 μm Response time: 14 ms – 999s (adjustable via software/ optional) Temperature resolution: 0,15 K (at object temperature >20°C and time constant >0,2s) System accuracy: ±1 % or ±1°C (whichever is greater) Repeatability: ±0,5 % or ±0,5°C (whichever is greater) Temperature coefficient: ±0,05 K/K or ±0,05 %/K Ambient temperature: -20-120 °C (sensor); -20-80 °C (controller) Storage temperature: -40°C - 85°C Power supply: 5-30 VDC Outputs: analogue: 0-5 V or 0-10 V (consumption: 9mA) Inputs: programmable functional input for external emissivity setting (0-5 VDC), Hold function, ambient temperature compensation (via USB programming interface/ optional) Emissivity: 0,100 - 1,100 adjustable via software/optional Transmissivity: 0,100 - 1,100 adjustable via software/optional Signal processing (parameter adjustable via software): peak hold, valley hold, average; extended hold function with threshold and hysteresis LED-functions: alarm indication, automatic aiming support, self diagnostic, temperature indication (via. temp. code) Environmental rating: IP65 for sensor head Scope of supply: Sensor incl. mounting nut, 6 m sensor cable, controller integrated after 3 m in connection cable, manual |
| Weight | 2 |
Please contact us to request a price quote for Micro-Epsilon (Eltrotec) - CSmi-SF15-C6/3, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
