Nidec - 075U3B300BFECA075140
| Manufacturer | Nidec |
|---|---|
| Part Number | 075U3B300BFECA075140 |
| Inner Code | 4271410 |
| Description | servo motor |
| Technical specification | Dimensions 9.38 × 2.95 × 5.01 in Manufacturer Control Techniques Product Type Unimotor FM Voltage 460 VAC Rated Current 1.43 Amps Stall Current 1.7 Amps Rated Speed 3000 RPM Frame Size 75 mm Motor Poles 6 Poles Resistance 21.07 Ohms inductance 52.65 mH Kt 14.16 lb-in/A (1.6 Nm/A) Ke 98 V/k rpm HorsePower 0.97 hp Kilowatt 0.72 kW RatedTorque 20.3 lb-in (2.29 Nm) Thermal Time Constant 58 s PeakTorque 71 lb-in (8 Nm) ShaftDiameter(mm) 19 mm ShaftLength(mm) 30 mm Brake none Connection Type Power & Signal 90Deg & rotatable size 1.0 Output Shaft Keyway w/ Half and Full Key included |
| Weight | 3.69224 |
Please contact us to request a price quote for Nidec - 075U3B300BFECA075140, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy 075U3B300BFECA075140 by Nidec in United Kingdom?
You can purchase 075U3B300BFECA075140 by Nidec from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the 075U3B300BFECA075140?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Nidec in United Kingdom?
While we are not the official distributor or seller of Nidec in United Kingdom, we source our products from reliable channels and offer you original Nidec equipment at competitive prices.
How can I access 075U3B300BFECA075140 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 075U3B300BFECA075140 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 075U3B300BFECA075140?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
