Nord - SK13063AZDSH-63SP/4 BRE5 RG

Manufacturer Nord
Part Number SK13063AZDSH-63SP/4 BRE5 RG
Inner Code 5124559
Description helical worm gear motor
Technical specification

Engine speed 1.370 rpm
Translation 1,343.63
Levels 3
Output speed 1,000 rpm
Operating factor 0.80
Output torque M2 (Nm) 475.00
Power (kW) 0.120
Voltage (V) 230/400
Frequency (Hz) 50
Efficiency class IE3
S1 operating mode
Motor protection class IP55
Insulation class F
Rated current 1 (AMP) 0.68
Rated current 2 (AMP) 0.39
Cosine 1 0.66
M3 gearbox design
Housing type hollow shaft flange B14
35H7 wave measure
Open ventilation, with transport safety
Cover cover for shrink disc
Position of the cover cover at A
Torque Support/Torque Support Console
Position of the torque support B-side 45°
Shrink Washer With Shrink Washer
Position of the shrink disk Shrink disc at A
Circuit type star
Terminal box layer/cable entry with 1/I

Braking torque (Nm) 5
230VWS-205VGS brake voltages
Precima brake supplier
Rust-proof, dust-proof brake, rust-proof design
IP55 brake protection
BR55PW Brake Series
Lubricant type Synth. ISO VG 680 oil
CLP PG 680 oil grade
Lubricant quantity (l) 1,800
Color 7031 Blue Gray
Paint type solid color
Basic painting instruction (2)
Location/number of type plate Getr. TS right mount (at A)
CE logo Yes
CCC logo No
Mexico NOM certificate No
UL No
CSA No
DoE CC No
CSA ev No
Alto Rendimento No
Korea Energy Label No
Looteil cover
shrink disk
Cable connector 18502020+O-ring M20
Weight 32
