Nord - SK1SIS50VF-IEC71-71SP/4 TF 175E
| Manufacturer | Nord |
|---|---|
| Part Number | SK1SIS50VF-IEC71-71SP/4 TF 175E |
| Inner Code | 4803842 |
| Description | IEC motor worm gear |
| Technical specification | Design: as already delivered with serial number 203448269-100 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Product name worm gear IEC motor Motor speed 1.415 rpm Translation 80.00 Output speed 18,000 rpm Operating factor 1.10 Output torque M2 (Nm) 62.60 Power (kW) 0.250 Voltage (V) 230/400 Frequency (Hz) 50 Efficiency class IE3 S1 operating mode Motor protection class IP55 Insulation class F Current Rating 1 (AMP) 1.21 Nominal current 2 (AMP) 0.70 Cosine 1 0.71 Universal gearbox design Housing type B5 solid shaft flange IEC71 B14 C105 mounting cylinder Position of the output shaft shaft at B (VB) Wave size 20X40 Flange type II-angular profile with inner recess Flange diameter (mm) 125 Flange bracket flange at B (FB) Aluminum flange material Venting Without venting Thermal motor protection cold conductor, 3x155°C Star circuit type Lubricant type Synth. ISO VG 680 oil Lubricant supplier Klüber CLP PG 680 oil grade Lubricant quantity (l) 0.095 Painting instructions Without painting CE logo Yes CCC logo No Mexico NOM certificate No UL No CSA No DoE CC No CSA ev No Alto Rendimento No Korea Energy Label No Lot part 2. Transmission type plate 2nd motor nameplate Type frequency inverter/starter SK 175E-301-340-B-ASI Mat. -No. Inverter/Starter 275229360 Version/data PTC input 1 brake control Soft start functionality reversing functionality Diagnostic interface RS232 RJ12 Status LEDs setpoint potentiometer AS-interface on board 2x Dig In, 2x Dig Out Ext. 24VDC power supply Rated power FU (kW) 3,000 Power rating FU (HP) 4,000 FU: input voltage 3AC 200-500V, + -10%, 47-63Hz Output current (A) 7.5 Protection class inverter/starter IP55 (standard) Location frequency inverter/starter 1 TI SK TIE4-M12-ASI signal connector SK TIE4-M12-INI DIN 1 SK TIE4-M12-INI DIN 2 SK TIE4-HAN10E-M2B-LE power input Pos. M12-ASI 4R Item M12-INI DIN 1.4L Item M12-INI DIN 2 5L Pos. HAN10E-MXB-LE 3L FU: UL approval Yes |
| Weight | 15 |
Please contact us to request a price quote for Nord - SK1SIS50VF-IEC71-71SP/4 TF 175E, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy SK1SIS50VF-IEC71-71SP/4 TF 175E by Nord in United Kingdom?
You can purchase SK1SIS50VF-IEC71-71SP/4 TF 175E by Nord from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the SK1SIS50VF-IEC71-71SP/4 TF 175E?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Nord in United Kingdom?
While we are not the official distributor or seller of Nord in United Kingdom, we source our products from reliable channels and offer you original Nord equipment at competitive prices.
How can I access SK1SIS50VF-IEC71-71SP/4 TF 175E catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for SK1SIS50VF-IEC71-71SP/4 TF 175E on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for SK1SIS50VF-IEC71-71SP/4 TF 175E?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
