Nord - SK1SMI75/H10AZ-IEC80-80LH/4 HM TF
| Manufacturer | Nord |
|---|---|
| Part Number | SK1SMI75/H10AZ-IEC80-80LH/4 HM TF |
| Inner Code | 5141233 |
| Technical specification | Serial number: 203890264-100
SK1SMI75/H10AZ-IEC80-80LH/4 HM TF
Product name: Worm gear IEC motor
Motor type: 3-phase AC motor
Motor speed: 1,425 rpm
Ratio: 250.00
Stages: 2
Output speed: 5,700 rpm
Service factor: 1.00
Output torque M2 (Nm) 374.00
Power (kW) 0.370
Voltage (V) 200/346
Frequency (Hz) 50
Efficiency class: IE3
Duty mode: S1
Motor protection class: IP66
Insulation class: F
Rated current 1 (AMP) 1.96
Rated current 2 (AMP) 1.13
Cosine 1 0.70
Gearbox design: Universal
Mounting: Spur gear pre-stage pre-stage at T1
Housing type: Hollow shaft flange B14
Mounting cylinder IEC80 B14 C120
Shaft dimension 35H7
Shaft material: 1.4057 / X17CrNi16-2 / AISI431
Special shaft part number: 000000000060737710
Ventilation: Without venting
Thermal motor protection: PTC thermistor, 3x155°C
Connection type: Star
Terminal box position/cable entry: 1/I
Lubricant type: Synthetic Oil ISO VG 680
Lubricant supplier Klüber
Oil class CLP PG 680
Lubricant quantity (l) 0.420
Color 7031 Blue-gray
Paint type: Standard paint
Painting specification NSD4+
Type code/terminal code: GTS+MTS Std / KK neutral
CE logo: Yes
Caution: The service factor is less than or equal to 1.0. The gearbox will be overloaded if the installed motor power is demanded for a prolonged period. We cannot accept any liability for damage resulting from this. |
| Weight | 28 |
Please contact us to request a price quote for Nord - SK1SMI75/H10AZ-IEC80-80LH/4 HM TF, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
