Nord - SK4282AZ-100AP/4 CUS BRE40 HL TF
| Manufacturer | Nord |
|---|---|
| Part Number | SK4282AZ-100AP/4 CUS BRE40 HL TF |
| Inner Code | 4813235 |
| Description | Parallel shaft transmission brake motor |
| Technical specification | Design: as already delivered with the serial number 202544628.100, but with motor in IE3 (energy efficiency class) and in a 3KW version possible. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Product name Parallel shaft transmission brake motor Motor type 3-Ph AC motor CUS Engine speed 1,765 rpm Translation 76.70 Output speed 23,000 rpm Operating factor 1.30 Output torque M2 (Nm) 1,245.00 Power (kW) 3,000 Power (HP) 4,000 Voltage (V) 230/460 Frequency (Hz) 60 Efficiency class Premium EFF according to EisAct CONT S1 operating mode Motor protection class IP55 Insulation class F Engine ambient temperature 40°C Rated current 1 (AMP) 10.20 Rated current 2 (AMP) 5.10 Cosine 1 0.79 M1 transmission design Housing type hollow-shaft-flange-B14 Wave measure 1,9375" Venting Pressure venting Thermal motor protection cold conductor, 3x155°C Star circuit type Terminal box layer/ cable connector 1/I Braking torque (Nm) 40 460VWS-205VGS brake voltages Brake Precima supplier Hand ventilation With hand ventilation Position of the hand ventilation 2 IP55 brake protection class BR55PW Brake Series Lubricant type Mobil 600 XP 220 Lubricant supplier Mobil CLP 220 grade oil Lubricant quantity (Qts) 4.440 Shade approx. 9007 grey aluminium Varnish type solid color Basic painting instruction (2) CE logo Yes CCC logo No Mexico NOM Certificate Yes UL E191510 CSA 189340 DoE CC CC 092 B CSA ev 189340 Alto Rendimento No Korea Energy Label No Loteil hand ventilation lever |
| Weight | 88 |
Please contact us to request a price quote for Nord - SK4282AZ-100AP/4 CUS BRE40 HL TF, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
