Omega - PF-DC-24
| Manufacturer | Omega |
|---|---|
| Part Number | PF-DC-24 |
| Inner Code | 5046790 |
| Description | Proportional Valve Amplifier Board Amplifier Electromagnetic Proportional Valve Controller (Color : Single proportional) |
| Technical specification | Response speed: 0.2-5s Load impedance: 10/40 Euro (load 40 Euro, The input voltage can only be 48V and can only be connected between F (DC+) and GND. Control signal input: 0~10VDC FUSE: 3A/250V Flutter frequency: 0-500HZ Ambient temperature: 0-65 C Temperature drift (maximum): 0.3mA/C Applicable Control Types Control all direct-acting and pilot-operated, overflow proportional pressure flow valves without potential feedback. With ramp generator, the rising and falling time can be adjusted separately, and the upper current limit can also be adjusted./ Lower limit setting. Power supply Stagger Protection function. All products are manufactured by SMD patch process, small size and anti-corrosion. Strong interference, good quality and low price. English description of terminal P(DC+) - Pressure Input Power Supply DC24V F(DC+) - Flow Input Power Supply DC24V or DC48V P = Pressure GND -- Common End of Input Power Supply F = Flow P+ - Pressure Valve Positive DC = DC P--negative pressure valve F+-flow valve alignment F--flow valve negative 12V-Auxiliary Power Supply for Variable Resistance GND - Control Common Point P (VIN) - Pressure input signal point F(vin) - Flow Input Signal Point Potentiometer Definition P (MAX) - Pressure Maximum Adjustment on PCB P (MIN) - Pressure Minimum Adjustment (factory has been adjusted, no need to adjust) P(UP) - Pressure Slope Rise Time (Minimum Output) P(DOWN) - Pressure Slope Decline Time (Minimum Output Adjustment) F (UP) - Increase time of flow ramp (minimum for factory departure) F (DOWN) - Flow Slope Decline Time (Minimum Output) F(MAX) - Flow Maximum Adjustment F (MIN) - Flow Minimum Adjustment |
| Weight | 0.001 |
Please contact us to request a price quote for Omega - PF-DC-24, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy PF-DC-24 by Omega in United Kingdom?
You can purchase PF-DC-24 by Omega from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the PF-DC-24?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Omega in United Kingdom?
While we are not the official distributor or seller of Omega in United Kingdom, we source our products from reliable channels and offer you original Omega equipment at competitive prices.
How can I access PF-DC-24 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for PF-DC-24 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for PF-DC-24?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
