Orbinox - Typ EXN / DN 200
| Manufacturer | Orbinox |
|---|---|
| Part Number | Typ EXN / DN 200 |
| Inner Code | 4956537 |
| Custom Code | 84818061 |
| Technical specification | short-length intermediate flange slider, sealing on one side, for installation between flanges in accordance with EN 1092-2 PN 10 nominal size DN 200 GJL 250/6G 25 housing, epoxy coated RAL 5015 AISI 304 stainless steel knife (1.4301) AISI 430 (1.4016) stainless steel piston rod Epoxy-coated steel construction bracket Contact protection stainless steel AISI 304 (1.4301) Stuffbox glasses up to DN 300 aluminum, from DN 350 ductile cast iron PTFE-soaked synthetic fiber (type ST) stuffing box with EPDM O-ring EPDM sealing ring Type A sealing clamping ring (standard), stainless steel AISI 304 (1.4301) Actuation double-acting pneumatic actuator made of aluminum Control pressure 5-7 bar allowable differential pressure in flow direction DN 50 to 250 = 10 bar, DN 300 to DN 400 =6 bar DN 450 = 5 bar, DN 500 to DN 600 = 4 bar Accessories Without flange sealing and mounting material Identical to EX DN 200 with OS 249130-005 |
| Weight | 39 |
Please contact us to request a price quote for Orbinox - Typ EXN / DN 200, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
