Osram - Oti Dali 50/220-240/1A4 Lt2 L G2

Manufacturer Osram
Part Number Oti Dali 50/220-240/1A4 Lt2 L G2
Inner Code 5123218
Description Led Driver
Technical specification

Electrical data:
Nominal input voltage: 220…240 V
Mains frequency: 0/50/60 Hz
Input voltage AC: 198…264 V
Input voltage DC: 176…276 V
Current set: DALI / LEDset / Programmable
Total harmonic distortion: < 15 %
Power factor λ: > 0.95
Efficiency in full-load: 90 %
Device power loss: 6.0 W
Networked standby power: ≤ 0.17 W
Protective conductor current: <0.5 mA
Inrush current: 20 A
Max. ECG no. on circuit breaker 10 A (B) : 13
Max. ECG no. on circuit breaker 16 A (B) : 20
Max. ECG no. on circuit breaker 25 A (B) : -
Surge capability (L/N-Ground) : 2 kV
Surge capability (L-N) : 1 kV
Nominal output voltage: 15…54 V
U-OUT (working voltage) : < 60 V
Nominal output current: 600…1400 mA
Output current LEDset open: 300 mA
Output current LEDset shorted: 1400 mA
Default output current: 300 mA
Output current tolerance: ±3 %
Output ripple current (100 Hz) : < 1 %
Output PSTLM: ≤1
Output SVM: ≤0.4
Nominal output power: 12…50 W
Maximum output power: 50 W
Galvanic isolation: SELV

Dimensions & weight:
Mounting hole spacing, length: 350.0 mm
Product weight: 240.00 g
Cable cross-section, input side: 0.5…1.5 mm²
Cable cross-section, output side: 0.5…1.5 mm²
Wire preparation length, input side: 8.0…9.0 mm
Wire preparation length, output side: 8.0…9.0 mm
Length: 360.0 mm
Height: 21.0 mm
Width: 30.0 mm

Colors & materials:
Casing material: Metal

Temperatures & operating conditions:
Ambient temperature range: -25…+50 °C
Maximum temperature at tc test point: 75 °C
Max.housing temperature in case of fault: 110 °C
Temperature range at storage: -40…+85 °C
Permitted rel. humidity during operation: 5…85 %

Lifespan:
ECG lifetime: 50000 / 100000 h

Additional product data:
Encapsulated: No
Predecessor EAN: 4052899028098

Capabilities:
Programming interface: DALI, LEDset
Dimmable: Yes
Dimming interface: DALI-2 / Touch DIM / Touch DIM Sensor
Dimming range: 1…100 %
Dimming method: Amplitude Modulation
Constant lumen function: Programmable
Overheating protection: Automatic reversible
Overload protection: Non-reversible
Short-circuit protection: Automatic reversible
No-load proof: Yes
Intended for no-load operation: No
Max. cable length to lamp/LED module: 2.0 m
Suitable for fixtures with prot. class: I
Suitable for emergency lighting: Yes
Type of connection, input side: Push terminal
Type of connection, output side: Push terminal
DALI-2 Diagnostic Data: Yes
Number of channels: 1
Control interface: DALI
DALI-2 Energy Data: Yes

Programming:
Programming device: DALI magic
Tuner4TRONIC: Yes
Tuner4TRONIC Field App: Yes

Programmable features
Operating Current: Yes
Constant Lumen: Yes
Lamp Operating Time: Yes
Driver Guard: Yes
DALI Settings: Yes
Emergency Mode: Yes
DALI-2 Luminaire Data: Yes
Soft Switch Off: Yes
Dim to Dark: Yes
TouchDIM + Sensor: Yes
Corridor Functionality: Yes
OEM Key: Yes

Certificates & standards:
Approval marks – approval: CE / EL / VDE-ENEC / VDE-EMC / EAC / CCC / RCM / BIS
Standards: Acc. to EN 61347-1/Acc. to EN 61347-2-13/Acc. to EN 55015/Acc. to EN 61547/Acc. to EN 61000-3-2/Acc. to EN 62384/Acc. to EN 62386
Type of protection: IP20
Weight 0.24
