Planetroll - Typ 0,25D4MR3-1/2(160,14h6x30)
| Manufacturer | Planetroll |
|---|---|
| Part Number | Typ 0,25D4MR3-1/2(160,14h6x30) |
| Inner Code | 4689089 |
| Description | Variable speed transmission drive unit |
| Custom Code | 8501 51 00 |
| Technical specification | consisting of: 1) Three-phase motor 2) Control transmission “p l a r o m a s t e r” 3) Control element 4) Baseboard 5) Painting Technical data: Control element: right Design: B5 Installation position: 1 Speed range: 0 to approx. 600 rpm Output torques: approx. 7.0 Nm from 10 to 220 rpm approx. 3.1 Nm at 600 rpm Drive components 1 501-15237 3 PCS Three-phase motor on the drive side 0.25/0.28 kW, 1395/1695 rpm, 230/400 V, 50 Hz, 1.33/0.76 A 460 V 60 Hz 0.75A, IP 55, Isol.Kl.F, energy efficiency class IE2, 1 cold-conductor temperature sensor,; Aluminum terminal box, 1x M25x1.5/1x M16x1.5 cable entry, size 71, B14-105 2 302-01923 3 PCS Plaromaster type MR3 variable speed gearbox on the drive side: for BG 71, B14-105 engine mounting output side: flange: B5-Ø160, output shaft 14h6 x 30 3 302-01466 3 PCS Control element type HVK 5 for AR2-AR5/MR3+MR5: Handwheel (d0=50) with fine adjustment scale; rough scale 0 - 12, fine scale 0 - 100 4 302-02300 3 PCS Baseboards (1 pair) for MR3 variable speed transmission 5 602-08879 3 PCS + RAL 9006 white aluminum painting |
| Weight | 12 |
Please contact us to request a price quote for Planetroll - Typ 0,25D4MR3-1/2(160,14h6x30), or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
