Planetroll - 602-05460, Type: 0,55D2MR3P31-5,4-2(136,16h6x40)
| Manufacturer | Planetroll |
|---|---|
| Part Number | 602-05460, Type: 0,55D2MR3P31-5,4-2(136,16h6x40) |
| Inner Code | 4014455 |
| Description | Variable speed drive unit |
| Custom Code | 85015100 |
| Technical specification | Variable speed drive unit planetroll Type 0,55D2MR3P31-5,4-2 (136,16h6x40) ================================= consisting of: --------------------- a) Special three-phase motor b) control gear "p l a r o m a s t e r" c) planetary gear Technical specifications ------------------------- Control element: right Design: B5 Installation position: 1 Speed range: 0 to approx. 222 1 / min (50 Hz network) Output torque: approx. 32.4 Nm from 2 to 120 rpm approx. 17.8 Nm at 222 rpm Drive components ------------------------------- 1. 501-00036 x 1 pcs drive side three-phase motor 0.55 kW, 2880/3440 rpm, 200-240 / 346-420 V, 50 Hz, 2.45 / 1.4 A, 200-254 / 346-440 V, 60 Hz, 2.35 / 1.35 A, IP 56, insulation class F, stainless steel, ON / OFF switch IP 55, 3m cable - 4x 1.5 square; Size 71, B14-105. 2. 302-01984 x 1 pcs Plaromaster variable speed gearbox type MR3 on the drive side: for motor mounting BG 71, B14-105 output side: B14-120, special output shaft Ø 16h6x24, attachment: planetary gear type P31 3. 302-01466 x 1 pcs Control element type HVK 5 for AR2-AR5 / MR3 + MR5: Handwheel (d0 = 50) with fine adjustment scale; Coarse scale 0 - 12, fine scale 0 - 100 4. 301-01283 x 1 pcs 1-stage planetary gear unit P31-2 (136) in flange design on the output side, reduction ratio i = 5.4 (Mmax.zul. = 80 Nm); B5 flange Ø136 / 120 / 94j6 (4x countersinking 6.6), output shaft Ø16h6 x 40. 5. 602-08879 x 1 pcs + Painting RAL 9006 white aluminum |
| Weight | 22 |
Please contact us to request a price quote for Planetroll - 602-05460, Type: 0,55D2MR3P31-5,4-2(136,16h6x40), or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
