Planetroll - (63,B14-120)MR3-3(112,15h6x30)(So)
| Manufacturer | Planetroll |
|---|---|
| Part Number | (63,B14-120)MR3-3(112,15h6x30)(So) |
| Inner Code | 4861903 |
| Custom Code | 84834059 |
| Technical specification | 602-11735 Planetroll drive unit variable transmission consisting of: -------------------- a) Control gear “p l a r o m a s t e r” specifications ------------------------ Control element links BauformB14 special Installation position2 (V6) Speed range0 up to approx. 1200 rpm (50 Hz network) Output torque range 6 Nm from 20 to 280 rpm approx. 1.55 Nm at 1200 rpm (P1= 0.25KW, n1= 2800 rpm 1 1 PCS plaromaster MR3 control gear drive-side: for motor mounting, size 63, B14-120 on the output side: B14 special flange diameter 112, 4x M5 on TK diameter 96 (Zng.120 316), 4x M5 on TK Ø 96; 32.5° offset (Zng.120 316), special output shaft Ø15h6x30 with 14.1x20 milling (Zng.120 4301). 302-014662 1 PC HVK 5 control element for AR2-AR5/MR3+MR5: Handwheel (d0=50) with fine adjustment scale; coarse scale 0 - 12, fine scale 0 - 100 |
| Weight | 5.7 |
