Planetroll - Typ 3,0D2MR9-3(28h6x60) /602-12364
| Manufacturer | Planetroll |
|---|---|
| Part Number | Typ 3,0D2MR9-3(28h6x60) /602-12364 |
| Inner Code | 4738271 |
| Description | Planetroll variable speed drive unit |
| Custom Code | 8501 52 20 |
| Technical specification | consisting of: a) Three-phase motor with efficiency class IE3 b) Variable speed transmission “p l a r o m a s t e r” Technical data: Control element: left Design: B14 (motor terminal box at the top) Installation position: 2 (V19) Speed range: approx. 0 to 1200/1440 rpm (50/60 Hz network) Output torques: approx. 45 Nm from 20/24 to 333/400 1/min approx. 17/14 Nm at 1200 /1440 1/min Drive components: 1 501-15908 1 PC on the drive side: three-phase motor 3.0 kW, 2910/3450 rpm, 230/400V 50Hz, 10.0/5.8A, 190-210/380-420V 50Hz, 190-240/380-480V, 60 Hz, protection class IP 55, insulation class F, efficiency class IE3, 1x bimetal switch and PTC thermistor, Aluminium terminal box, 4x M32x1.5 cable entry, size 100, B5 flange Ø250. 2 302-04626 1 PC Plaromaster type MR9 variable speed gearbox On the drive side: for BG 100/112, B5-250 motor mounting output side: B14-250, output shaft Ø28h6 x 60 3 302-04467 1 PC Control element type: FEW, free adjustment shaft diameter 12 x 30 4 602-08896 1 PC + Primer 2K -grey- 5 408-00094 1 PC Position indicator type: HRS, special scale 0-12, rising to the right (outer diameter 86.8 mm/made by SIKO) 6 905-00008 1 PC Traction fluid SANTOTRAC 50:0.25 l/bottle, “No original product” Manufacturer country USA. 7 905-00002 1 PC Traction fluid SANTOTRAC 50:1 l/bottle “No original product” Manufacturer country USA. |
| Weight | 72 |
Please contact us to request a price quote for Planetroll - Typ 3,0D2MR9-3(28h6x60) /602-12364, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
