Rittal - SK 3237.100

Manufacturer Rittal
Part Number SK 3237.100
Inner Code 4023460
Description TopTherm filter fan
Custom Code 84145915
Technical specification


execution
wall mounting
product description
Filter fans with diagonal fan technology are more pressure-stable and offer a more constant air output. The diagonal outflow direction ensures more even heat dissipation of the control cabinet.
Market-relevant product changes
The cover for the connection terminal is no longer part of the TopTherm filter fans since May 2024. During testing, it was found not to be required by the standards and does not impair either the function or operational safety.
Color
RAL 7035
scope of delivery
Completely ready-to-install unit, including fleece filter mat
fan
Axial, shaded-pole motor
air performance free blowing (with fleece filter)
At 50 Hz: 20 m³/h
At 60 Hz: 25 m³/h
Air output with outlet filter including fleece filter mat (number x order number)
1 x 3237200: 15/18 m³/h
2 x 3237200: 16/20 m³/h
rated operating voltage
230 V, 1~, 50 Hz/60 Hz
rated power Pel
At 50 Hz: 12 W
At 60 Hz: 10 W
Rated current max.
At 50 Hz: 0.065 A
At 60 Hz: 0.07 A
dimension
Width: 116.5 mm
Height: 116.5 mm
installation depth
43 mm
mounting cutout
Cutout width: 92 mm
Cutout height: 92 mm
Protection class IP according to IEC 60 529
IP 54 with fleece filter
IP56 with fleece filter and jet water hood
protection class NEMA
Type 12 with fleece filter
Type 3
Type 3R with fleece filter and jet water hood
backup fuse
Circuit breaker/fuse: 2 A
Notice
To increase the air output, a pleated filter can be used optionally (see characteristic curve). This can be used with both the filter and roof ventilators and the outlet filters.
For the filter fan 3237.XXX, the electrical connection is made via 2 single wires (length approx. 300 mm) on the device, for all other filter fans via spring terminal
Fan life (L10, 40 °C)
At 50 Hz: 55,000 h
At 60 Hz: 60,000 h
operating temperature range
-15 °C...55 °C
storage temperature range
-30 °C...70 °C
sound pressure level
At 50 Hz: 38 dB(A)
At 60 Hz: 43 dB(A)
packaging unit
1 piece
net weight
0.38 kg
gross weight
0.46 kg
customs tariff number
84145915
EAN
4028177637580
ETIM 9
EC000320
ETIM 8
EC000320
ECLASS 8.0
27180716
product description
SK filter fan TopTherm, 20/25 m³/h, 230 V, 1~, 50/60 Hz, WHT: 116.5 x 116.5 x 16 mm
Weight 0.38
