Rotex - 30334-5-2R-B9+III-110V-AC/DC-39-FR-H-01
| Manufacturer | Rotex |
|---|---|
| Part Number | 30334-5-2R-B9+III-110V-AC/DC-39-FR-H-01 |
| Inner Code | 5099833 |
| Description | solenoid valve |
| Technical specification | Type of Valve: 3/2 Spring Return Direct Acting Universal Valve Ordering Code: 30334-5-2R-B9+III-110V-AC/DC-39-FR-H-01 Item code: Port connection: 1/4" NPT (F) Orifice size (mm): 5mm Flow Factor (kV): 8 LPM Body material: stainless steel 316L with internal wetted parts of stainless steel 316L Manual Override: Manual Override Not Provided Seat Seal Material: NBR Media: Air, Clear Water Main Pressure: 0 - 10 bar Media temperature range: -25°C to +75°C Type of Solenoid: Flameproof Enclosure Ex d having integrated terminals, Horizontal Cable Entry M20x1.5mm (F) Size of Coil: III Enclosure material: cast epoxy powder coated aluminum Special Version: Inbuilt Full Rectifier with Surge Suppressor Voltage: 110V 50Hz/ 60Hz/ DC, 120V 50Hz/ 60Hz/ DC (-20%, +20%) Power of coil: 8W Insulation Class: Class H Approval: CE - ATEX Coil Certificate No.: ATEX TI22ATEX 278X Marking: Ex II 2GD Ex db IIC T6/T5 Gb Ex tb IIIC T80°C/ T95°C Db, IP66/ IP67 -40 °C < Ta < 60 °C FOR T6 -40 °C < Ta < 70 °C FOR T5 |
| Weight | 1 |
Please contact us to request a price quote for Rotex - 30334-5-2R-B9+III-110V-AC/DC-39-FR-H-01, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
