Rotork - Z692690502
| Manufacturer | Rotork |
|---|---|
| Part Number | Z692690502 |
| Inner Code | 3424325 |
| Description | spare Actuator |
| Technical specification | IQM25 F14 A [IP68] 24RPM 380/3/50 Wiring diagram 203B0000 Wiring diagram 203B0000 is described in IQ/IQT Control and Monitoring publication (PUB002-041) and includes: • CONTROL SUPPLY: 20 – 60VDC/40 – 120VAC or actuator derived 24VDC • CONTROL INPUTS: 6 inputs for open, close, stop/maintain, ESD and interlock signals, 20 – 60VDC/40 – 120VAC • INDICATION CONTACTS: 4 volt-free (SPST) latching contacts (S1-S4), rated at 120VAC/30VDC, 5mA to 5A, each configurable NO or NC to signal one of the following; open/closed or intermediate positions, moving (continuous or pulsing), Handwheel operation, local selected, remote selected, open/close interlock active, ESD active, motor tripped on torque in mid travel/going open/going closed, valve jammed, loss of power/phase or control supply, battery low, internal failure detected, thermostat tripped, programmable service alarms. • MONITOR AND AVAILABILITY RELAY: Independent relay with volt-free changeover contact, rated at 120VAC/30VDC, 5mA to 5A. De-energises in case of; loss of power/phase or control supply, local control or local stop selected (can be excluded), motor thermostat tripped or detected internal failure • ANALOGUE CONTROL/FEEDBACK: Proportional control over whole or part of valve stroke 0 to 5/10/20/mA or volt ranges, internally powered 4-20mA output proportional to position (Folomatic/CPT). Configurable for open, close or stay-put on loss of signal. Incorporates user adjustable deadband (percentage of signal) and motion inhibit time (seconds) for restricting hunting or over modulation caused by a fluctuating control signal. |
| Weight | 54 |
