Rotronic - HC2A-S3
| Manufacturer | Rotronic |
|---|---|
| Part Number | HC2A-S3 |
| Inner Code | 3320904 |
| Description | STANDARD METEO PROBE |
| Technical specification | Probe type Meteorological probe Humidity sensor Hygromer HT-1 Temperature sensor PT100 1/3 DIN Class B Long-term stability <1 %rh / year Accuracy w. adjustment profile "standard" ±0.8 %RH / ±0.1 K, at 10...30 °C Adjustment at 23 °C and 10, 35, 80 %RH Accuracy w. adjustment profile "High Precision" ±0.5 %RH / ±0.1 K, at 10...30 °C at 23 °C and 10, 20, 30, 40, 50, 60, 70, 80, 90 %RH Reproducibility Airchip <0.02 %rh / 0.01 K Response time t 63 <15 sec. Power consumption 3.3...5 VDC, Calibration @ 3.3 VDC / ~4.5 mA Dimensions Ø15 x 108 mm Operating range -50…80 °C / 0…100 %rh Allowed wind speed 20 m/s, with filter Exploitation software ROTRONIC HW4 Psychrometric calculations Dew or frost point Analogue outputs scaleable by the user Yes Software Update With internet and HW4 software User information from Software HW4 (devicemanager) Data processing via HW4 with interface cables Type of output signals 2 x 0…1 VDC Digital output signal (standard) UART Service Interface UART FDA/GAMP compatibility FDA 21 CFR Part 11 and GAMP compatible Probe adjustment by software 1 Point & multipoint %rh & °C Device Protection by password Yes Analog output signal (standard) 0…1 V = 0…100 %rh; 0…1 V = -40…60 °C Communication interfaces UART Reverse voltage protection Mechanically in the connector Max. cable length Up to 5 m with passive cable. Up to 100 m with active cable. Probe protection Polycarbonate plastic cage, white Filter cartridge Polyethylene dust filter, white, 40 um Enclosure material Polycarbonate Filter type Polyethylene, 40 μm |
| Weight | 0.017 |
