RTK Regeltechnik - MV 5211 / 16122812/010
| Manufacturer | RTK Regeltechnik |
|---|---|
| Part Number | MV 5211 / 16122812/010 |
| Inner Code | 4988249 |
| Description | engine control valve |
| Custom Code | 84818059 |
| Technical specification | Motor control valve - MV 5211 series in continuous form nominal size DN 80, nominal pressure PN 16 Housing material ductile iron EN-GJS-400-18-LT Flanges according to DIN, machined according to ANSI 150 lbs. RF Spindle sealing: PTFE/carbon roof collars Characteristic/flow rate: equal percent/below the cone parabolic cone, metallic sealing Kvs value = 79 m³/h, stroke 35 mm Seat diameter 65 mm Surface treatment with zinc dust primer CE marking in accordance with Pressure Equipment Directive (PED) max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 250 °C Electrical actuator - type ReAct 30E-074 Positioning force 3 kN, including manual adjustment 230 V 50/60 Hz AC motor Setting speed 0.74 mm/s, stroke 35 mm Protection class IP 65 with pillars additional equipment: - additional limit switches (2 pieces) - Potentiometer 1000 ohms - RetranS2w type transmitter (2-wire) Output signal: 4.. 20 mA Effective direction: at 0% outlet valve closed Drive spindle extended at 0% output |
| Weight | 38 |
