How can I access MV5311+REACT100E-090+REPOS+1000OHM catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for MV5311+REACT100E-090+REPOS+1000OHM on our website. Visit our resources section or contact us directly for specific documents.

Catalogue
RTK Regeltechnik
MV 5311 DN 65 PN 25

RTK Regeltechnik - MV 5311 DN 65 PN 25

Q: Where can I buy MV5311+REACT100E-090+REPOS+1000OHM by RTK Regeltechnik in United Kingdom?

You can purchase MV5311+REACT100E-090+REPOS+1000OHM by RTK Regeltechnik from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.

Manufacturer	RTK Regeltechnik
Part Number	MV 5311 DN 65 PN 25
Inner Code	5119871
Custom Code	84818059
Technical specification	14122386/020 Motor control valve - MV 5311 series in continuous form nominal size DN 65, nominal pressure PN 25 Housing material ductile iron EN-GJS-400-18-LT Flanges with DIN sealing surface Spindle sealing: PTFE/carbon roof collars Characteristic/flow rate: equal percent/below the cone parabolic cone, metallic sealing Kvs value = 63 m³/h, stroke 35 mm Seat diameter 65 mm Surface treatment with zinc dust primer CE marking in accordance with Pressure Equipment Directive (PED) max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 250 °C Electrical actuator - type ReAct 60E-045 Positioning force 6 kN, including manual adjustment 230 V 50/60 Hz AC motor Adjustment speed 0.45 mm/s, stroke 35 mm Protection class IP 65 additional equipment: - additional limit switches (2 pieces) - digital positioner, type repOS with display input signal: 4.. 20 mA Feedback signal: 4.. 20 mA Effective direction: at 0% valve input closed Drive spindle extended at 0% input - Potentiometer 1000 ohms
Weight	50

Please contact us to request a price quote for RTK Regeltechnik - MV 5311 DN 65 PN 25, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy MV 5311 DN 65 PN 25 by RTK Regeltechnik in United Kingdom?

You can purchase MV 5311 DN 65 PN 25 by RTK Regeltechnik from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.

What is the price of the MV 5311 DN 65 PN 25?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of RTK Regeltechnik in United Kingdom?

While we are not the official distributor or seller of RTK Regeltechnik in United Kingdom, we source our products from reliable channels and offer you original RTK Regeltechnik equipment at competitive prices.

How can I access MV 5311 DN 65 PN 25 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for MV 5311 DN 65 PN 25 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for MV 5311 DN 65 PN 25?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
