Saia-Burgess - MBC1 R2
| Manufacturer | Saia-Burgess |
|---|---|
| Part Number | MBC1 R2 |
| Inner Code | 4882503 |
| Description | microswitch |
| Custom Code | 85365080 |
| Technical specification | MBC1 microswitch - Frame size: standard - Operating force: 2.8 N - Reverse shift force: 1.1 N - Rest position: 30.1 mm max. - Switching point: 29.3 +/- 0.64 mm - Differential travel: 0.05 mm max - Follow-up travel: 3.56 mm - Connections: screw terminals (6BA) - Circuit diagram: changeover (CO) - Actuator: telescopic plunger with roller (longitudinal) - Contact material: solid silver rivet + Beryllium three-tooth pen - Approval: CSA - Protection class: IP40 - Housing material: Die-cast aluminum - Actuating roller material: nylon - Special feature: none |
| Weight | 0.05 |
Please contact us to request a price quote for Saia-Burgess - MBC1 R2, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy MBC1 R2 by Saia-Burgess in United Kingdom?
You can purchase MBC1 R2 by Saia-Burgess from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the MBC1 R2?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Saia-Burgess in United Kingdom?
While we are not the official distributor or seller of Saia-Burgess in United Kingdom, we source our products from reliable channels and offer you original Saia-Burgess equipment at competitive prices.
How can I access MBC1 R2 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for MBC1 R2 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for MBC1 R2?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
