Sauter - ident.number: 144416
| Manufacturer | Sauter |
|---|---|
| Part Number | ident.number: 144416 |
| Inner Code | 4701933 |
| Description | 12-fold tool disc revolver |
| Technical specification | Revolver type: 0.5.901.012 Comm. Reference: 00-11.00934/1 Identification number: 120421 SAUTER 12-fold tool disc revolver 0.5.450.412 for driven tools Motor layout: rearward according to drawing 0.5.450.412-AZ07 (095397) Right version ----------------------- standard housing Nominal height 90 mm Direction of rotation: bidirectional Turret rotary drive and tool drive with 1 AC servomotor Installation and function: according to Wiring Diagram EP-1150 SK-1487 functional diagram and HP-496 hydraulic diagram Hydraulic turret lock Operating pressure 50 bar allowable mass distortion moment: 1.25 kgm≤ Swivel drive with self-locking ‹ Overload coupling including electrical ‹ monitoring Turret and tool drive is being prepared for the cultivation of -------------------- Siemens AC servomotor: 1 FT 6 064 - 6AK7 Servo motor is used by lathe manufacturer grown. 117734 Coolant device (steel) 5 bar to max. 25 bar 1.5.450.509 Coolant injection into the tool wheel in R position 75 mm; at 345 degrees 113537 Coupling for Siemens 1FT6 064 servomotor 104997 Accessories 1.5.450.090 Revolver case mounting Standard + 5 mm 119222 Final assembly parts connection A+B and K 133518 distributor according to 0.5.450.412-AZ07 Take cable length into account in accordance with 0.5.450,412 AZ01 Coupling for tool drive in position 3 a.m. distributor is attached by the machine manufacturer, therefore with cable ties on the ring bolt attach!! 133958 Sliding coupling 1.5.450.016 for revised tool drive with m=1.05 for tool wheel SW 220/D 25 mm Coupling profile in accordance with DIN 5480-W14 x 0.8 x 30 x 16 Performance data on the tool coupling Power = 20 Nm Power = 6 kW at 25% duty cycle - 10 min nzul = 6000 rpm at 25% ED - 10 min Drive motor in tool operation must be limited to these values 120421 SAUTER 12-fold tool disc 0.5.901.012/450.4 to accommodate tool holders after DIN 69 880 T1 in a radial arrangement Wrench size 220 mm Mounting holes for shaft diameter 25 mm Right version with Emco alignment system Position number sequence left-wise 1,2,... No. 1 at 3:00 Coolant supply in position R 75 mm; 345 degrees Brushed surface including clamping elements 147868 Locking plate SW 220 (without rotary distributor) 121930 Final assembly parts |
| Weight | 85 |
