Scherzinger - 4030-450-DM-37-2
| Manufacturer | Scherzinger |
|---|---|
| Part Number | 4030-450-DM-37-2 |
| Inner Code | 4437584 |
| Description | Magnetically coupled external gear pump |
| Technical specification | Variant: GS, GD, Exd, KL medium Name: lubricating, non-corrosive Rated operating temperature: 20±5°C operating range inlet pressure: 1,000Mbara Min. operating point: 0.16 l/min at 437 rpm (7.7 Hz), 5 bar, 1 mPas Nom. operating point: 6.00 l/min at 1735 rpm (30.4 Hz), 5 bar, 1 mPas Max. operating point: 13.94 l/min at 3,500 rpm (61.4 Hz), 5 bar, 1 mPas specifications Explosion protection: 2014/34/EU - II 2G Ex h IIC Gb X//II 2D Ex h IIC Db X Preferred direction of rotation: left (ccw), pump shaft view Swallow volume: 4.5 c³/U Connections: DIN ISO 228, G 1/2” perm. Pump inlet pressure ፦0.9... 88 bar Operating temperature range ፦20 to 130°C Temperature sensor inclusion: with M6 thread on the splitting pot Temperature sensor inclusion: with M6 thread in the lid construction materials Housing material: 1.4404 Gear material: PEEK mod. Waves: 1.4571 plain bearings: PEEK mod. stat. Seals: PTFE Shaft seal: magnetic coupling, max.2 Nm Sm2Co17 magnets, encapsulated in 1.4404 three-phase motor Explosion protection: 2014/34/EU - II 2G Ex db eb IIC T4 Gb Engine size: IEC71 Engine bit: IMB34 Flange diameter: 140mm Rated power: 0.37 kW Rated speed: 2,850 rpm Voltage: 230/400V, 50Hz, 3~ Protection type: IP 55 Efficiency class: IE2 Temperature monitoring: with 3x PTC thermistors Terminal box: top, view of motor shaft Important notes Please install a coarse filter with 50 µm mesh size in front of the pump pump not suitable for liquids with magnetic particles Pump not suitable for particulate media The purity class of the medium should be at least 19/17/14 according to ISO 4406 |
| Weight | 10 |
