Simplex - VLC-600
| Manufacturer | Simplex |
|---|---|
| Part Number | VLC-600 |
| Inner Code | 3778277 |
| Description | TrueAlarm LaserCOMPACT Smoke Sensor |
| Technical specification | (sampling pipe is ordered separately) 2098-9808 - Remote Red LED Status Indicator on single gang stainless steel plate; mounting requires a single gang box, 1 ½” minimum depth; connections are color coded wire leads. Sensor Voltage: 18 to 30 VDC, supplied from fire alarm control panel Sensor Current - 205 mA @ 24 VDC; supervisory and alarm Compatibility 4100ES/4010ES/4100U IDNet or MAPNET II addressable, communications, automatically selected. Loading - One address, one unit load per sensor. Electrical Terminations: Terminal blocks for 18 to 12 AWG Sensor Ambient: 14° F to 103° F (-10° C to 39° C) Sampled Air: -4° F to 140° F (-20° C to 60° C) Sensor Humidity: 10-95% RH, non-condensing Sampling Network - Maximum area of coverage = 8000 ft2, maximum pipe length in accordance with Vision Systems computer design tool (ASPIRE) and NFPA standards UL Listed Velocity Range: 0 to 4000 ft/min (0 to 1200 m/min) Alarm Sensitivity Range - 0.016% to 4.08%/ft obscuration, selected at the fire alarm control panel; NOTE: UL listed evacuation alarm sensitivity is not to be less sensitive than 0.625%/ft. Recognized Sensitivity Levels: Three levels, selectable and designated as required at the fire alarm control panel. Sensor Service Access -Internal DB-9, RS-232 connection for a service computer using VESDA, Vconfig Pro software program (authorized service access only) Enclosure Rating - NEMA 1 (IP 30) |
| Weight | 1.9 |
Please contact us to request a price quote for Simplex - VLC-600, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy VLC-600 by Simplex in United Kingdom?
You can purchase VLC-600 by Simplex from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the VLC-600?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Simplex in United Kingdom?
While we are not the official distributor or seller of Simplex in United Kingdom, we source our products from reliable channels and offer you original Simplex equipment at competitive prices.
How can I access VLC-600 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for VLC-600 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for VLC-600?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
