Soldo - SF01200-20W01L4
| Manufacturer | Soldo |
|---|---|
| Part Number | SF01200-20W01L4 |
| Inner Code | 4614830 |
| Description | Limit switch box |
| Custom Code | 5365007 |
| Technical specification | ELR.SO.SF01200-20W01L4 SF series limit switch housing, stainless shaft steel, mounted on bushings, mounting type ISO F05 and shaft VDI/VDE3845, independently adjustable cams, 2x switches as follows: electromechanical switch SPDT, silver-plated contacts, max. load capacity 5A @ 250VAC, 0.6A @125VDC, 3A @24VDC, min 50mA @ 24VDC (resistive load), screw terminal strips with passage - solenoid valve poles, black polyester - powder coating, 2x M20x1.5 - cable entries, UV - durable and self-extinguishing polycarbonate - display hood V0, red and green optical position indicator, weatherproof limit switch box, weatherproof IP66/IP67, Ambient temperature range: -40 - +80°C, copper-free heavy duty aluminum body and cover galvanized steel SF series limit switch box, stainless steel shaft mounted on bushings, ISO F05 mounting pattern and VDI/VDE3845 shaft, independent adjustable cams, SPDT electromechanical switches, silver plated contacts, rating max. 5A @250VAC, 0.6A @125VDC, 3A @24VDC, rating min. 50mA @24VDC (resistive load), 2x switches as for following spec., screw terminal strips with pass through Solenoid valve poles, black polyester powder coating, 2x M20x1.5 cable entries, UV resistant and V0 self extinguish Polycarbonate indicator dome, red and green visual position indicator, weather proof limit switch box, weather proof IP66/IP67, ambient temperature range: -40 - +80°C, copper-free aluminum heavy duty body and cover die-cromated |
| Weight | 1.5 |
Please contact us to request a price quote for Soldo - SF01200-20W01L4, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
