Soldo - P/N: 57527, Type: ELR.SO.SB70200-20X11A2
| Manufacturer | Soldo |
|---|---|
| Part Number | P/N: 57527, Type: ELR.SO.SB70200-20X11A2 |
| Inner Code | 3384797 |
| Description | Limit switch housing |
| Custom Code | 8536 5007 |
| Technical specification | SB series limit switch housing: stainless steel shaft, ISO F05 mounting pattern and VDI/ VDE3845 shaft, independently adjustable cams, inductive switches P+ F, Type NJ2-V3-N Namur 2-wire, sensitivity 2 mm, Rated voltage 8 V DC, screw terminal strip with additional implementation, standard black polyester powder coating, No. 2 cable entries M20x1.5, UV-resistant and V0 self-extinguishing polycarbonate display dome, red and green optical position indicator, ATEX and IECEx certified box up to SIL3, certification mark: Ex II 2GD Exi, weather-resistant IP66/IP67, Ambient temperature range: -20+80, robust aluminum housing, impact-resistant and UV-resistant polycarbonate cover SB series limit switch box: stainless steel shaft mounted On bushings, ISO F05 mounting pattern and VDI/VDE3845 shaft, independent adjustable cams, inductive proximity P+F type NJ2-V3-N Namur 2 wire, Sensibility 2 mm, nominal voltage 8 V DC, current Consumption <= 1mA (face covered) >= 3mA (face not covered), no. 2 switch/sensors as for the following spec. , Screw terminal strip with extra pass-through, standard Black polyester powder coating, no. 2 M20x1.5 cable Entries, UV resistant and V0 self-extinguish polycarbonate Indicator dome, red and green visual position indicator, ATEX and IECEx certified box up to SIL3, certification Marking: Ex II 2GD Exi, weather proof IP66/IP67, ambient Temperature range: -20+80, aluminum heavy duty body, Shock resistant and UV resistant polycarbonate cover |
| Weight | 1 |
Please contact us to request a price quote for Soldo - P/N: 57527, Type: ELR.SO.SB70200-20X11A2, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy P/N: 57527, Type: ELR.SO.SB70200-20X11A2 by Soldo in United Kingdom?
You can purchase P/N: 57527, Type: ELR.SO.SB70200-20X11A2 by Soldo from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the P/N: 57527, Type: ELR.SO.SB70200-20X11A2?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Soldo in United Kingdom?
While we are not the official distributor or seller of Soldo in United Kingdom, we source our products from reliable channels and offer you original Soldo equipment at competitive prices.
How can I access P/N: 57527, Type: ELR.SO.SB70200-20X11A2 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for P/N: 57527, Type: ELR.SO.SB70200-20X11A2 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for P/N: 57527, Type: ELR.SO.SB70200-20X11A2?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
