Stahl - 8570/11-306-B-04-0-00-XXX / 289533
| Manufacturer | Stahl |
|---|---|
| Part Number | 8570/11-306-B-04-0-00-XXX / 289533 |
| Inner Code | 5067952 |
| Description | 16 A wall socket |
| Custom Code | 85366990 |
| Technical specification | explosion-proof 8570/11-3.. -B Detailed number of poles: 2P + PE (1P + N + PE) Coding (time setting): 99 Housing material: polyamide, glass-reinforced Silicone-free: Yes Range of application (zones): 1,2,21,22 Scope: European Union (ATEX) Gas explosion protection: II 2 G Ex db eb IIC T6... T5 Gb Dust explosion protection: II 2 D Ex tb IIIC T73 °C Db Min. ambient temperature: -40 °C Max. ambient temperature: +45 °C Rated operation current: 16 A Min.2 ambient temperature: -40 °C Max. ambient temperature.2: +65 °C Rated operating current2:10 A Ambient temperature min. F: -40 °F Ambient temperature max. F: +113 °F Ambient temperature min. °F 2: -40 °F Ambient temperature max. °F 2: +149 °F Protection class IP (IEC 60529): IP66 Protection class IP (IEC 60079): IP64 Impact resistance (IEC 60079): 7.00 J Impact resistance (IEC 62262): IK10 Introduction of 1 clamp.: 0 mm Technical data: This product is silicone-free Gas - explosion protection: Ex II 2 G Ex db eb IIC T6... T5 Gb Dust - explosion protection: Ex II 2 D Ex tb IIIC T73°C Db Test certificate: PTB 03 ATEX 1227, IECEx PTB 05.0023, Rated operating current: 10... 16 A Rated voltage: 200... 250V AC Rated frequency [Fn]: 50/60Hz Number of poles: 2P+PE Code color: blue Safety contact position: 6h Ambient temperature: -40 °C < Ta < 45 °C... 65 °C Protection class: IP66 Auxiliary contact: - Introductions: Position 1:8161/7-M20-1304 with reduction to M20 Position 2:8290/3-M20 with reduction to M20 |
| Weight | 1.12 |
